General Electric TEL136080WL – 3‑Pole 80 A 600 V AC Molded Case Breaker, Thermal‑Magnetic, 65 kAIC @ 480 V

Product Title

General Electric TEL136080WL – 3‑Pole 80 A 600 V AC Molded Case Breaker, Thermal‑Magnetic, 65 kAIC @ 480 V

Product Description

The General Electric TEL136080WL is a 3‑pole, 80 Amp, 600 V AC molded case circuit breaker engineered for dependable overcurrent protection in commercial and industrial electrical distribution systems. Part of GE’s TEL series, this breaker features a thermal‑magnetic trip unit providing fixed Long-Time (LI) and Instantaneous protection to reliably safeguard circuits from overloads and short‑circuit conditions.

Designed with feed‑thru or lug connections, the TEL136080WL is ideal for branch and feeder circuit protection in panelboards, switchboards, and other distribution equipment where high interrupting capacity is necessary. Its 65 kAIC @ 480 V AC interrupting rating ensures robust performance in demanding electrical environments.

Key Features

• Poles: 3

• Amperage: 80 A

• Voltage: 600 V AC (maximum)

• Type: Molded Case Circuit Breaker (TEL Series)

• Thermal‑magnetic trip with Long‑Time (LI) & Instantaneous protection

• Interrupting capacity: 65 kAIC @ 480 V AC

• Suitable for commercial and industrial power distribution applications

Technical Specifications

• Manufacturer: General Electric

• Catalog Number: TEL136080WL

• Series / Frame: TEL

• Phase: Three‑Phase

• Trip Type: Thermal‑Magnetic (LI & Instantaneous)

• Voltage Rating: 600 V AC

• Interrupting Rating: 65 kAIC @ 480 V AC

• Frequency Rating: 50/60 Hz

• Connection Type: Feed‑Thru / Lug Terminals

• Protection: Overload and short‑circuit
