General Electric TFJ236125WL 125A 3-Pole Molded Case Circuit Breaker – Bolt-On Mount – 600VAC

The General Electric TFJ236125WL is a dependable molded case circuit breaker designed to provide effective overload and short-circuit protection in commercial and industrial electrical systems. Built on the TFJ frame platform, this 3-pole breaker features a thermal magnetic non-interchangeable trip unit rated at 125 amperes at 40°C. Its bolt-on mounting configuration ensures secure installation, while standard line and load end terminals allow convenient wiring connections. With both AC and DC interrupting ratings, this breaker is suitable for a wide range of power distribution applications requiring durable and reliable protection.

Product Specifications

• Brand: General Electric
• Model: TFJ236125WL
• Amperage: 125 Amp
• Number of Poles: 3 Pole
• Breaker Type: Molded Case Circuit Breaker
• Mount Type: Bolt-On
• Voltage: 600VAC
• Frequency: 50/60 Hz
• Frame Type: F / TFJ Frame
• Warranty: One Year

Technical Specifications

• Trip Unit Type: Thermal Magnetic Non-Interchangeable
• Protection Type: Overload and Short Circuit Protection
• Frame Style: TFJ
• Connection Type: Bolt-On
• Trip Setting Range: 600-1250
• Standard Lug Type: Line and Load End Terminals Included
• Operating Temperature Rating: 40°C
• Construction: Heavy-Duty Industrial Design

Voltage and Ratings

• 25 kA @ 240V AC
• 22 kA @ 480V AC
• 18 kA @ 600V AC
• 10 kA @ 250V DC
• Maximum Rated Voltage: 600VAC
• Frequency Rating: 50/60 Hz

Product Data

• Manufacturer: General Electric GE
• Part Number: TFJ236125WL
• Condition: New Surplus / Certified Reconditioned (subject to availability)
• Poles: 3
• Mounting Style: Bolt-On
• Included Terminals: Line and Load End Terminals Standard
• Application: Commercial and Industrial Power Distribution
• Warranty Coverage: 1 Year In-House Warranty
• Suitable For: Panelboards, Switchgear, Distribution Equipment

Important Note

Please verify compatibility with your electrical system, panelboard, frame type, and voltage requirements before purchase. This breaker includes standard line and load terminals. Installation should be carried out by a qualified electrician in compliance with all local electrical codes and safety regulations.
