Square D HDA36015 Molded Case Circuit Breaker – 150A – 2-Pole / 1-Phase – 600V – 18kA @ 480V – I-Line Style Plug-In – PowerPact HDA Series

The Square D HDA36015 is a 150A, 2-pole, 1-phase molded case circuit breaker from the Square D / Schneider Electric PowerPact Type HDA Series. It is designed for compatible electrical distribution applications and features a non-interchangeable trip.

The HDA36015 is rated for 600V and provides an 18kA interrupting rating at 480V with standard interrupting capacity. It features an I-Line style plug-in connection, B & C phase connection, and is suitable for reverse-fed applications. The breaker is supplied as a complete breaker.

Specifications:

• Manufacturer: Square D / Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Product Family: PowerPact
• Series: HDA
• Type: HDA
• Catalog No.: HDA36015
• Current Rating: 150A
• Number of Poles: 2-Pole
• Phase: 1-Phase
• Phase Connection: B & C
• Voltage Rating: 600V
• Interrupting Rating: 18kA @ 480V
• Interrupting Capacity: Standard
• Trip Type: Non-Interchangeable
• Mounting / Connection: I-Line Style Plug-In
• Reverse Feed: Suitable for Reverse-Fed Applications
• Breaker Configuration: Complete Breaker
• Application: Electrical Distribution and Overcurrent Protection
• Brand: Square D / Schneider Electric

Part Numbers & Identification:

• Manufacturer Part Number (MPN): HDA36015
• Catalog Number: HDA36015
• Model: HDA36015
• Product Family: Square D PowerPact Molded Case Circuit Breakers
• Series: HDA
• Type: HDA
• Brand: Square D
• Manufacturer: Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 2-Pole, 150A
• Trip Configuration: Non-Interchangeable Trip
• UPC:785901419105

Compatibility:

Designed for use with compatible Square D / Schneider Electric PowerPact HDA Series electrical distribution equipment that accepts I-Line style plug-in molded case circuit breakers. The HDA36015 provides 150A, 2-pole protection for compatible 600V, 1-phase electrical distribution applications.

The breaker uses a B & C phase connection, has a non-interchangeable trip, and is suitable for reverse-fed applications as specified. Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, phase connection, available fault current, pole configuration, trip requirements, and mounting arrangement before installation.

Certifications:

• UL Listed
• PowerPact HDA Series
• 150A Rated
• 2-Pole / 1-Phase
• 600V Rated
• 18kA @ 480V Interrupting Rating
• Standard Interrupting Capacity
• Non-Interchangeable Trip
• I-Line Style Plug-In
• B & C Phase Connection
• Suitable for Reverse-Fed Applications
• Complete Breaker
