Square D HDA36035 35 Amp Molded Case Circuit Breaker – 3 Pole – 600 V – 18 kA@480 V – I-Line Style Plug-In – PowerPact Series

The Square D HDA36035 is a 35 Amp, 3-pole molded case circuit breaker from the Square D PowerPact Series, Type HDA. It is rated for 600 V with an 18 kA interrupting rating at 480 V and features standard interrupting capacity. The breaker uses thermal-magnetic protection with a non-interchangeable trip unit and LI (Long-Time and Instantaneous) trip functions. It is designed for I-Line style plug-in mounting, uses an ABC phase connection, and is suitable for reverse-fed applications.

Specifications

• Manufacturer: Schneider Electric
• Brand: Square D
• Product Type: Molded Case Circuit Breaker
• Series: PowerPact
• Type: HDA
• Catalog Number / MPN: HDA36035
• Primary Rating: 35 Amp
• Poles / Configuration: 3 Pole
• Phase: 3 Phase
• Phase Connection: ABC
• Voltage: 600 V
• Interrupting Rating: 18 kA @ 480 V
• Interrupting Capacity: Standard
• Trip Type: Thermal-Magnetic
• Trip Unit: Non-Interchangeable
• Trip Functions: LI – Long-Time and Instantaneous
• Connection / Mounting: I-Line Style Plug-In
• Application: Suitable for Reverse-Fed Applications

Part Numbers & Identification

• Manufacturer: Schneider Electric
• Brand: Square D
• Catalog Number: HDA36035
• Series: PowerPact
• Type: HDA
• Current Rating: 35 A
• Pole Count: 3 Pole
• Product Type: Thermal-Magnetic Molded Case Circuit Breaker
• Phase Connection: ABC
• Trip Unit: Non-Interchangeable
• Trip Functions: LI – Long-Time and Instantaneous
• Connection: I-Line Style Plug-In
• UPC: 785901422235

Compatibility

The Square D HDA36035 is designed for compatible Schneider Electric / Square D PowerPact Type HDA and I-Line style applications. It is suitable for reverse-fed applications as specified. Verify the specific panelboard, system voltage, phase connection, mounting configuration, and breaker compatibility before installation.

Certifications

• UL Listed
