Square D HDL36090 Molded Case Circuit Breaker – 90A – 3-Pole / 3-Phase – 600V – 18kA @ 480V – Feed-Thru – PowerPact HDL Series

The Square D HDL36090 is a 90A, 3-pole, 3-phase molded case circuit breaker from the Square D PowerPact Type HDL Series. It features thermal-magnetic protection with a non-interchangeable trip and Long-Time and Instantaneous (LI) trip functions.

The breaker is rated for 600V and provides an 18kA interrupting rating at 480V with standard interrupting capacity. It uses a feed-thru configuration, includes line- and load-side lug terminals, and is suitable for reverse-fed applications. The breaker is UL Listed.

Specifications:

• Manufacturer: Square D / Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Product Family: PowerPact
• Series: HDL
• Type: HDL
• Catalog No.: HDL36090
• Current Rating: 90A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V
• Interrupting Rating: 18kA @ 480V
• Interrupting Capacity: Standard
• Protection Type: Thermal-Magnetic
• Trip Type: Non-Interchangeable
• Trip Functions: Long-Time and Instantaneous (LI)
• Mounting / Connection: Feed-Thru
• Terminal Type: Line-Side and Load-Side Lug Terminals
• Reverse Feed: Suitable for Reverse-Fed Applications
• Application: Electrical Distribution and Overcurrent Protection

Part Numbers & Identification:

• Manufacturer Part Number (MPN): HDL36090
• Catalog Number: HDL36090
• Model: HDL36090
• Brand: Square D
• Manufacturer: Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Product Family: PowerPact Molded Case Circuit Breakers
• Series: HDL
• Type: HDL
• Breaker Configuration: 3-Pole, 90A
• Trip Functions: Long-Time and Instantaneous (LI)
• UPC:785901955917

Compatibility:

Designed for use with compatible Square D PowerPact HDL Series electrical distribution equipment that accepts HDL Series molded case circuit breakers. The HDL36090 provides 90A, 3-pole thermal-magnetic protection for compatible 600V electrical distribution applications.

The breaker features a non-interchangeable LI trip, feed-thru configuration, and line- and load-side lug terminals. It is also suitable for reverse-fed applications as specified.

Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, trip requirements, terminal arrangement, reverse-feed suitability, and installation specifications before installation.

Certifications:

• UL Listed
• PowerPact HDL Series
• 90A Rated
• 3-Pole / 3-Phase
• 600V Rated
• 18kA @ 480V Interrupting Rating
• Standard Interrupting Capacity
• Thermal-Magnetic Protection
• Non-Interchangeable Trip
• Long-Time and Instantaneous (LI) Trip Functions
• Feed-Thru Configuration
• Line-Side and Load-Side Lug Terminals
• Suitable for Reverse-Fed Applications
