Square D HGL36040 Molded Case Circuit Breaker – 40A – 3-Pole / 3-Phase – 600V – 35kA @ 480V – Feed-Thru – PowerPact HGL Series

The Square D HGL36040 is a 40A, 3-pole, 3-phase thermal-magnetic molded case circuit breaker from the Square D PowerPact HGL Series. It is designed for compatible electrical distribution applications and provides high interrupting capacity.

The HGL36040 is rated for 600V and provides a 35kA interrupting rating at 480V. It features a feed-thru configuration with line-side and load-side lug terminals, a non-interchangeable trip, and Long-Time and Instantaneous (LI) trip functions. The breaker is UL Listed and suitable for reverse-fed applications.

Specifications:

• Manufacturer: Square D / Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Product Family: PowerPact
• Series: HGL
• Type: HGL
• Catalog No.: HGL36040
• Current Rating: 40A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V
• Interrupting Rating: 35kA @ 480V
• Interrupting Capacity: High
• Protection Type: Thermal-Magnetic
• Trip Functions: Long-Time and Instantaneous (LI)
• Trip Type: Non-Interchangeable
• Mounting / Connection: Feed-Thru
• Terminal Type: Line-Side and Load-Side Lug Terminals
• Reverse Feed: Suitable for Reverse-Fed Applications
• Breaker Configuration: Complete Breaker
• Application: Electrical Distribution and Overcurrent Protection
• Brand: Square D / Schneider Electric

Part Numbers & Identification:

• Manufacturer Part Number (MPN): HGL36040
• Catalog Number: HGL36040
• Model: HGL36040
• Product Family: Square D PowerPact Molded Case Circuit Breakers
• Series: HGL
• Type: HGL
• Brand: Square D
• Manufacturer: Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 40A
• Trip Configuration: Non-Interchangeable, Long-Time and Instantaneous (LI)
• UPC:785901598749

Compatibility:

Designed for use with compatible Square D PowerPact HGL Series electrical distribution equipment that accepts HGL Series molded case circuit breakers. The HGL36040 provides 40A, 3-pole thermal-magnetic overcurrent protection for compatible 600V electrical distribution applications.

The breaker features high interrupting capacity, a feed-thru configuration, line-side and load-side lug terminals, and a non-interchangeable LI trip configuration. It is also suitable for reverse-fed applications as specified.

Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, trip-unit requirements, terminal arrangement, reverse-feed requirements, and installation specifications before installation.

Certifications:

• UL Listed
• PowerPact HGL Series
• 40A Rated
• 3-Pole / 3-Phase
• 600V Rated
• 35kA @ 480V Interrupting Rating
• High Interrupting Capacity
• Thermal-Magnetic Protection
• Long-Time and Instantaneous (LI) Trip Functions
• Non-Interchangeable Trip
• Feed-Thru Configuration
• Line-Side and Load-Side Lug Terminals
• Suitable for Reverse-Fed Applications
• Complete Breaker
