Square D HJA36015 Molded Case Circuit Breaker – 15A – 3-Pole / 3-Phase – 600V AC – 100kA @ 240V – I-Line Plug-On – PowerPact HJA Series

The Square D HJA36015 is a 15A, 3-pole, 3-phase molded case circuit breaker from the Square D / Schneider Electric PowerPact HJA Series. It is designed for protection of compatible commercial and industrial electrical systems.

The HJA36015 is rated for 600V AC and features I-Line plug-on mounting with thermal-magnetic protection. Its trip unit provides Long-Time and Instantaneous (LI) trip functions for overload and short-circuit protection.

The supplied source information contains conflicting interrupting-rating data. The detailed interrupting-rating section specifies 100kA @ 240V AC, 65kA @ 480V AC, and 25kA @ 600V AC, which is used in this listing.

Specifications:

• Manufacturer: Square D / Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Product Family: PowerPact
• Series: HJA
• Frame Type: HJA
• Catalog No.: HJA36015
• Current Rating: 15A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V AC
• Interrupting Rating: 100kA @ 240V AC; 65kA @ 480V AC; 25kA @ 600V AC
• Protection Type: Thermal-Magnetic
• Trip Functions: Long-Time and Instantaneous (LI)
• Mounting / Connection: I-Line Plug-On
• Application: Commercial and Industrial Electrical System Protection
• Weight: Approximately 2.4 lb
• Brand: Square D / Schneider Electric

Part Numbers & Identification:

• Manufacturer Part Number (MPN): HJA36015
• Catalog Number: HJA36015
• Model: HJA36015
• Product Family: Square D PowerPact Circuit Breakers
• Series: HJA
• Frame Type: HJA
• Brand: Square D
• Manufacturer: Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 15A
• UPC: 785901419044
• GTIN: 00785901419044

Compatibility:

Designed for use with compatible Square D / Schneider Electric PowerPact HJA electrical distribution equipment that accepts I-Line plug-on molded case circuit breakers. The HJA36015 provides 15A, 3-pole thermal-magnetic protection for compatible 600V AC electrical systems.

Always verify the specific panelboard or electrical equipment model, approved breaker type, I-Line compatibility, system voltage, available fault current, pole configuration, interrupting rating, trip-unit requirements, and installation specifications before installation.

Certifications:

• PowerPact HJA Series
• 15A Rated
• 3-Pole / 3-Phase
• 600V AC Rated
• 100kA @ 240V AC Interrupting Rating
• 65kA @ 480V AC Interrupting Rating
• 25kA @ 600V AC Interrupting Rating
• Thermal-Magnetic Protection
• Long-Time and Instantaneous (LI) Trip Functions
• I-Line Plug-On Mounting
• Square D / Schneider Electric Product
