Siemens HQR23B225H 225 Amp Molded Case Circuit Breaker – 3 Pole – 240 V – 100 kA@240 V – Feed-Thru – QR Series

The Siemens HQR23B225H is a 225 Amp, 3-pole, 3-phase molded case circuit breaker from the Siemens QR Series, Type HQR2H. It is rated for 240 V and provides a 100 kA interrupting rating at 240 V, with very high interrupting capacity. The breaker features thermal-magnetic protection with a non-interchangeable trip unit and LI (Long-Time and Instantaneous) trip functions. It is designed for feed-thru mounting and includes line and load-side lug terminals.

Specifications

• Manufacturer: Siemens
• Brand: Siemens
• Product Type: Molded Case Circuit Breaker
• Series: QR
• Type: HQR2H
• Catalog Number / MPN: HQR23B225H
• Primary Rating: 225 Amp
• Poles / Configuration: 3 Pole
• Phase: 3 Phase
• Voltage: 240 V
• Interrupting Rating: 100 kA @ 240 V
• Interrupting Capacity: Very High
• Trip Type: Thermal-Magnetic
• Trip Unit: Non-Interchangeable
• Trip Functions: LI – Long-Time and Instantaneous
• Connection / Mounting: Feed-Thru
• Terminals: Line & Load-Side Lug Terminals

Part Numbers & Identification

• Manufacturer: Siemens
• Brand: Siemens
• Catalog Number: HQR23B225H
• Series: QR
• Type: HQR2H
• Current Rating: 225 A
• Pole Count: 3 Pole
• Product Type: Thermal-Magnetic Molded Case Circuit Breaker
• Trip Unit: Non-Interchangeable
• Trip Functions: LI – Long-Time and Instantaneous
• Connection: Feed-Thru
• Terminals: Line & Load-Side Lug Terminals
• UPC:786679079195

Compatibility

The Siemens HQR23B225H is intended for compatible Siemens QR Series Type HQR2H electrical distribution applications.
