HLA36040 - Square D - Molded Square D HLA36040 40 Amp Molded Case Circuit Breaker – 3 Pole – 600 V – 100 kA@480 V – I-Line Plug-In – PowerPact HLA SeriesCase Circuit Breaker

The Square D HLA36040 is a 40 Amp, 3-pole, 3-phase molded case circuit breaker from the Square D PowerPact HLA Series. It is rated for 600 V and provides a 100 kA interrupting rating at 480 V. The breaker features current-limiting protection, an I-Line style plug-in connection, and thermal-magnetic protection with a non-interchangeable LI (Long-Time and Instantaneous) trip unit. It is suitable for reverse-fed applications and is UL Listed.

Specifications

• Manufacturer: Schneider Electric
• Brand: Square D
• Product Type: Molded Case Circuit Breaker
• Series: PowerPact HLA
• Type: HLA
• Catalog Number / MPN: HLA36040
• Primary Rating: 40 Amp
• Poles / Configuration: 3 Pole
• Phase: 3 Phase
• Phase Connection: ABC
• Voltage: 600 V
• Interrupting Rating: 100 kA @ 480 V
• Interrupting Capacity: Current Limiting
• Trip Type: Thermal-Magnetic
• Trip Unit: Non-Interchangeable
• Trip Functions: LI – Long-Time and Instantaneous
• Connection / Mounting: I-Line Style Plug-In
• Application: Suitable for Reverse-Fed Applications

Part Numbers & Identification

• Manufacturer: Schneider Electric
• Brand: Square D
• Catalog Number: HLA36040
• Series: PowerPact HLA
• Type: HLA
• Current Rating: 40 A
• Pole Count: 3 Pole
• Product Type: Thermal-Magnetic Molded Case Circuit Breaker
• Trip Unit: Non-Interchangeable
• Trip Functions: LI – Long-Time and Instantaneous
• Connection: I-Line Style Plug-In
• UPC: 785901507338

Compatibility

The Square D HLA36040 is designed for compatible Square D PowerPact HLA Series applications and I-Line style panelboards. It is suitable for reverse-fed applications as specified.

Certifications

• UL Listed
