Eaton HLD3600F Molded Case Circuit Breaker Frame – 600A – 3-Pole / 3-Phase – 600V – 65kA @ 480V – Bolt-On – Series C HLD

The Eaton HLD3600F is a 600A, 3-pole, 3-phase molded case circuit breaker frame from the Eaton / Cutler-Hammer Series C HLD Series. It is designed for compatible electrical distribution applications and features thermal-magnetic protection with a high interrupting capacity of 65kA at 480V AC.

The HLD3600F is a frame-only product; the trip unit is not included. It is rated for 600V and uses a bolt-on mounting configuration for compatible electrical distribution equipment.

Specifications:

• Manufacturer: Eaton / Cutler-Hammer / Westinghouse
• Product Type: Molded Case Circuit Breaker Frame
• Product Family: Series C
• Series: HLD
• Type: HLD
• Catalog No.: HLD3600F
• Current Rating: 600A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V
• Interrupting Rating: 65kA @ 480V AC
• Interrupting Capacity: High
• Protection Type: Thermal-Magnetic
• Mounting Type: Bolt-On
• Configuration: Frame Only
• Trip Unit: Not Included
• Application: Electrical Distribution and Overcurrent Protection
• Brand: Eaton / Cutler-Hammer

Part Numbers & Identification:

• Manufacturer Part Number (MPN): HLD3600F
• Catalog Number: HLD3600F
• Model: HLD3600F
• Product Family: Eaton Series C Molded Case Circuit Breakers
• Series: HLD
• Type: HLD
• Brand: Eaton / Cutler-Hammer
• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker Frame
• Breaker Configuration: 3-Pole, 600A
• Product Status: Frame Only
• UPC:786679138014

Compatibility:

Designed for use with compatible Eaton / Cutler-Hammer Series C HLD electrical distribution equipment that accepts the HLD frame. The HLD3600F is a 3-pole, 600A frame rated for 600V applications with a 65kA interrupting rating at 480V AC.

Because this is a frame-only product, the appropriate trip unit must be selected separately and verified for compatibility with the specific frame and application.

Always verify the specific panelboard or electrical equipment model, approved HLD frame and trip-unit combination, system voltage, available fault current, pole configuration, mounting arrangement, and installation requirements before installation.

Certifications:

• Series C HLD Series
• 600A Rated Frame
• 3-Pole / 3-Phase
• 600V Rated
• 65kA @ 480V AC Interrupting Rating
• High Interrupting Capacity
• Thermal-Magnetic
• Bolt-On Mounting
• Frame Only
• Trip Unit Not Included
