Siemens Sentron HLXD63B500L 500 Amp Molded Case Circuit Breaker – 3 Pole – 600V – 65 kA @ 480V – HLXD Frame

The Siemens Sentron HLXD63B500L is a 500A, three-pole molded case circuit breaker featuring a thermal-magnetic trip unit with non-interchangeable Long-Time and Instantaneous (LI) protection. Designed for commercial and industrial power distribution applications, it provides high interrupting capacity and bolt-on mounting.

Specifications

• Manufacturer: Siemens
• Product Series: Sentron
• Catalog Number: HLXD63B500L
• Frame Type: HLXD
• Rated Current: 500A
• Poles: 3 Pole
• Phase: 3-Phase
• Voltage Rating: 600V
• Interrupting Capacity: 65 kAIC @ 480V
• Breaking Capacity: High
• Trip Unit: Thermal-Magnetic
• Trip Functions: Long-Time and Instantaneous (LI)
• Trip Configuration: Non-interchangeable
• Mounting Type: Bolt-on
• Terminal Connections: Lugs not included
• Operating Temperature: 40°C

Part Numbers & Identification

• Manufacturer Part Number (MPN): HLXD63B500L
• Brand: Siemens
• Product Family: Sentron
• Frame Designation: HLXD
• UPC:040892921649

Compatibility

Suitable for Siemens Sentron HLXD-frame applications requiring a 500A, three-pole molded case circuit breaker with non-interchangeable thermal-magnetic LI trip protection and bolt-on mounting.
