Siemens HLXD63B600L Molded Case Circuit Breaker – 600A – 3-Pole / 3-Phase – 600V – 65kA @ 480V – Bolt-On – SENTRON HLXD Series

The Siemens HLXD63B600L is a 600A, 3-pole, 3-phase thermal-magnetic molded case circuit breaker from the Siemens SENTRON HLXD Series. It is designed for compatible electrical distribution applications and provides overcurrent protection through thermal-magnetic operation.

The HLXD63B600L is rated for 600V and provides a 65kA interrupting rating at 480V with high interrupting capacity. It features a bolt-on mounting configuration, a non-interchangeable trip, and Long-Time and Instantaneous (LI) trip functions. The breaker is rated for operation at 40°C and is supplied as a complete breaker without lugs.

Specifications:

• Manufacturer: Siemens
• Product Type: Molded Case Circuit Breaker
• Product Family: SENTRON
• Series: HLXD
• Type: HLXD
• Catalog No.: HLXD63B600L
• Current Rating: 600A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V
• Interrupting Rating: 65kA @ 480V
• Interrupting Capacity: High
• Protection Type: Thermal-Magnetic
• Trip Type: Non-Interchangeable
• Trip Functions: Long-Time and Instantaneous (LI)
• Mounting Type: Bolt-On
• Breaker Configuration: Complete Breaker
• Lugs: Not Included
• Temperature Rating: 40°C
• Application: Electrical Distribution and Overcurrent Protection
• Brand: Siemens

Part Numbers & Identification:

• Manufacturer Part Number (MPN): HLXD63B600L
• Catalog Number: HLXD63B600L
• Model: HLXD63B600L
• Product Family: Siemens SENTRON Circuit Breakers
• Series: HLXD
• Type: HLXD
• Brand: Siemens
• Manufacturer: Siemens
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 600A
• Trip Configuration: Non-Interchangeable LI Trip
• UPC:783643539785

Compatibility:

Designed for use with compatible Siemens SENTRON HLXD Series electrical distribution equipment that accepts HLXD Series bolt-on molded case circuit breakers. The HLXD63B600L provides 600A, 3-pole thermal-magnetic overcurrent protection for compatible 600V electrical distribution applications.

The breaker is supplied without lugs, so the appropriate lug configuration must be verified for the specific installation. Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, trip-unit requirements, lug selection, mounting arrangement, temperature requirements, and installation specifications before installation.

Certifications:

• Siemens SENTRON HLXD Series
• 600A Rated
• 3-Pole / 3-Phase
• 600V Rated
• 65kA @ 480V Interrupting Rating
• High Interrupting Capacity
• Thermal-Magnetic Protection
• Non-Interchangeable Trip
• Long-Time and Instantaneous (LI) Trip Functions
• Bolt-On Mounting
• Complete Breaker
• Lugs Not Included
• 40°C Rated
