Eaton HMCP003A0 Motor Circuit Protector – 3A – 3-Pole / 3-Phase – 600V – 65kA @ 480V – Feed-Thru – Series C HMCP

The Eaton HMCP003A0 is a 3A, 3-pole, 3-phase molded case motor circuit protector (MCP) from the Eaton / Cutler-Hammer / Westinghouse Series C Type HMCP F-Frame. It provides magnetic-only, instantaneous protection for compatible motor circuit applications.

The HMCP003A0 is rated for 600V and provides a 65kA interrupting rating at 480V. It features a non-interchangeable instantaneous trip, a 9–30A magnetic range, and a 0.69–2.5A motor FLA range. The breaker has a feed-thru configuration with standard line- and load-side lug terminals.

Specifications:

• Manufacturer: Eaton / Cutler-Hammer / Westinghouse
• Product Type: Molded Case Circuit Breaker
• Product Name: Motor Circuit Protector (MCP)
• Product Family: Series C
• Series: Series C
• Type: HMCP
• Frame: F-Frame
• Catalog No.: HMCP003A0
• Current Rating: 3A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V
• Interrupting Rating: 65kA @ 480V
• Protection Type: Magnetic Only
• Trip Function: Instantaneous (I)
• Trip Type: Non-Interchangeable
• Mounting / Configuration: Feed-Thru
• Terminal Type: Standard Line- and Load-Side Lug Terminals
• Magnetic Range: 9–30A
• Motor FLA Range: 0.69–2.5A
• Style Number: 6630C87G03
• Application: Motor Circuit Protection
• Brand: Eaton / Cutler-Hammer

Part Numbers & Identification:

• Manufacturer Part Number (MPN): HMCP003A0
• Catalog Number: HMCP003A0
• Model: HMCP003A0
• Product Family: Eaton Series C Molded Case Circuit Breakers
• Series: Series C
• Type: HMCP
• Frame: F-Frame
• Brand: Eaton / Cutler-Hammer
• Manufacturer: Eaton
• Product Type: Motor Circuit Protector / Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 3A
• Style Number: 6630C87G03
• UPC:786679150702

Compatibility:

Designed for use with compatible Eaton / Cutler-Hammer Series C Type HMCP motor circuit protection applications. The HMCP003A0 is a 3-pole, 3A MCP with magnetic-only instantaneous protection, a 9–30A magnetic range, and a 0.69–2.5A motor FLA range.

The breaker uses a feed-thru configuration with standard line- and load-side lug terminals. Always verify the specific motor application, panelboard or electrical equipment model, approved MCP type, system voltage, available fault current, pole configuration, magnetic trip requirements, terminal arrangement, and installation requirements before installation.

Certifications:

• Series C HMCP
• F-Frame
• 3A Rated
• 3-Pole / 3-Phase
• 600V Rated
• 65kA @ 480V Interrupting Rating
• Magnetic-Only Protection
• Instantaneous (I) Protection
• Non-Interchangeable Trip
• Feed-Thru Configuration
• Standard Line- and Load-Side Lug Terminals
• 9–30A Magnetic Range
• 0.69–2.5A Motor FLA Range
• Motor Circuit Protector (MCP)
