Eaton HMCP003A0Y 3 Amp Motor Circuit Protector – 3 Pole – 600 V – 65 kA@480 V – Feed-Thru – F Frame – Series C

The Eaton HMCP003A0Y is a 3 Amp, 3-pole, 3-phase motor circuit protector from the Eaton / Cutler-Hammer / Westinghouse Series C, Type HMCP. It features an F-frame configuration and is rated for 600 V with a 65 kA interrupting rating at 480 V. The protector uses magnetic-only protection with a non-interchangeable trip unit and I (Instantaneous) protection. It is designed for feed-thru mounting and includes standard line- and load-side lug terminals.

Specifications

• Manufacturer: Eaton
• Brand: Cutler-Hammer
• Product Type: Motor Circuit Protector (MCP)
• Series: Series C
• Type: HMCP
• Frame: F Frame
• Catalog Number / MPN: HMCP003A0Y
• Style Number: 6630C87G03
• Primary Rating: 3 Amp
• Poles / Configuration: 3 Pole
• Phase: 3 Phase
• Voltage: 600 V
• Interrupting Rating: 65 kA @ 480 V
• Trip Type: Magnetic Only
• Trip Unit: Non-Interchangeable
• Trip Functions: I – Instantaneous Protection Only
• Magnetic Range: 9–30 A
• Motor FLA Range: 0.69–2.5 A
• Connection / Mounting: Feed-Thru
• Terminals: Standard Line & Load-Side Lug Terminals

Part Numbers & Identification

• Manufacturer: Eaton
• Brand: Cutler-Hammer
• Catalog Number: HMCP003A0Y
• Style Number: 6630C87G03
• Series: Series C
• Type: HMCP
• Frame: F Frame
• Current Rating: 3 A
• Pole Count: 3 Pole
• Product Type: Magnetic-Only Motor Circuit Protector
• Trip Unit: Non-Interchangeable
• Trip Functions: I – Instantaneous Protection Only
• Magnetic Range: 9–30 A
• Motor FLA Range: 0.69–2.5 A
• Connection: Feed-Thru
• Terminals: Standard Line & Load-Side Lug Terminals
• UPC:786679150795

Compatibility

The Eaton HMCP003A0Y is intended for compatible Eaton / Cutler-Hammer Series C Type HMCP motor control and motor protection applications.
