Eaton HMCP030H1C Molded Case Circuit Breaker – 30A – 3-Pole – 600V – 65kA @ 480V – Feed-Thru – Series C HMCP

The Eaton HMCP030H1C is a 30A, 3-pole, 3-phase molded case circuit breaker from the Cutler-Hammer Series C HMCP type. It is an F-frame motor circuit protector (MCP) rated for 600V, with a 65kA interrupting rating at 480V.

The HMCP030H1C provides magnetic-only, instantaneous protection with a non-interchangeable trip. It features a 90–300A magnetic range, is designed for motor circuit protection, and includes non-aluminum line- and load-side lug terminals in a feed-thru configuration.

Specifications:

• Manufacturer: Eaton / Cutler-Hammer / Westinghouse
• Product Type: Molded Case Circuit Breaker
• Product Type / Application: Motor Circuit Protector (MCP)
• Series: Series C
• Type: HMCP
• Frame: F Frame
• Catalog No.: HMCP030H1C
• Current Rating: 30A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V
• Interrupting Rating: 65kA @ 480V
• Protection Type: Magnetic Only
• Trip Type: Non-Interchangeable
• Trip Function: Instantaneous Protection Only (I)
• Magnetic Range: 90–300A
• Motor FLA Range: 6.9–25.2A
• Mounting / Configuration: Feed-Thru
• Terminal Configuration: Non-Aluminum Line- and Load-Side Lug Terminals
• Application: Motor Circuit Protection

Part Numbers & Identification:

• Manufacturer Part Number (MPN): HMCP030H1C
• Catalog Number: HMCP030H1C
• Product Family: Series C Molded Case Circuit Breakers
• Series: Series C
• Type: HMCP
• Frame: F Frame
• Brand: Eaton / Cutler-Hammer
• Manufacturer: Eaton
• Product Type: Motor Circuit Protector
• Model: HMCP030H1C
• Breaker Configuration: 3-Pole, 30A
• upc:786679150825

Compatibility:

Designed for use with compatible Eaton / Cutler-Hammer Series C HMCP electrical distribution and motor circuit protection applications. The HMCP030H1C is a 3-pole, 30A, 600V F-frame motor circuit protector with magnetic-only instantaneous protection and a 65kA interrupting rating at 480V.

The breaker has a 90–300A magnetic range and is intended for motor circuit protection. Always verify the specific electrical equipment, motor application, system voltage, available fault current, pole configuration, trip requirements, terminal arrangement, and installation requirements before installation.

Certifications:

• 65kA Interrupting Rating @ 480V
• Magnetic-Only Protection
• Instantaneous Protection Only (I)
• Motor Circuit Protector (MCP)
• Non-Interchangeable Trip
• 90–300A Magnetic Range
• 30A Rated
• 3-Pole / 3-Phase
• 600V Rated
• F-Frame
• Feed-Thru Configuration
• Genuine Eaton / Cutler-Hammer Product
