Eaton HMCP050K2C Molded Case Circuit Breaker – 50A – 3-Pole – 600V – 65kA – Feed-Thru – Series C HMCP

The Eaton HMCP050K2C is a 50A, 3-pole, 3-phase molded case circuit breaker from the Series C HMCP family with an F-frame configuration. It is rated for 600V and provides a 65kA interrupting rating at 480V.

The HMCP050K2C is a Motor Circuit Protector (MCP) designed for magnetic-only instantaneous protection. It features a non-interchangeable instantaneous trip, a 50–500A magnetic range, and non-aluminum line- and load-side lug terminals. It is intended for compatible motor circuit protection applications.

Specifications:

• Manufacturer: Eaton / Cutler-Hammer / Westinghouse
• Product Type: Molded Case Circuit Breaker
• Series: Series C
• Type: HMCP
• Frame: F Frame
• Catalog No.: HMCP050K2C
• Current Rating: 50A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V
• Interrupting Rating: 65kA at 480V
• Connection: Feed-Thru
• Protection Type: Magnetic Only
• Trip Function: Instantaneous Protection Only (I)
• Trip Type: Non-Interchangeable
• Device Type: Motor Circuit Protector (MCP)
• Magnetic Range: 50–500A
• Motor FLA Range: 11.5–42.1A
• Terminals: Non-Aluminum Line & Load Side Lug Terminals
• Product Family: Series C HMCP Molded Case Circuit Breakers

Part Numbers & Identification:

• Manufacturer Part Number (MPN): HMCP050K2C
• Catalog Number: HMCP050K2C
• Product Family: Eaton Series C HMCP
• Series: C
• Type: HMCP
• Frame: F Frame
• Brand: Eaton / Cutler-Hammer
• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Model: HMCP050K2C\
• upc:786679150832

Compatibility:

Designed for use with compatible Eaton / Cutler-Hammer Series C HMCP motor circuit protection applications. The HMCP050K2C is a 3-pole, 50A, 600V Motor Circuit Protector with magnetic-only instantaneous protection, feed-thru construction, and a 50–500A magnetic range.

Because this is an MCP with instantaneous protection only, it should be applied in accordance with the requirements of the specific motor circuit and associated overload protection. Always verify the equipment or panelboard model, motor application, system voltage, available fault current, terminal configuration, and applicable installation requirements before installation.

Certifications:

• Series C HMCP
• F-Frame
• 50A Rated
• 3-Pole / 3-Phase
• 600V Rated
• 65kA Interrupting Rating at 480V
• Motor Circuit Protector (MCP)
• Magnetic-Only Protection
• Instantaneous Protection Only
• 50–500A Magnetic Range
• Feed-Thru Connection
• Non-Interchangeable Trip
