Eaton HMCP070M2C Molded Case Circuit Breaker – 70A – 3-Pole – 600V – 65kA @ 480V – Feed-Thru – Series C HMCP

The Eaton HMCP070M2C is a 70A, 3-pole, 3-phase molded case motor circuit protector (MCP) from the Eaton / Cutler-Hammer / Westinghouse Series C Type HMCP F-Frame. It provides magnetic-only, instantaneous protection for motor circuit applications rather than thermal-magnetic protection.

The HMCP070M2C is rated for 600V with a 65kA interrupting rating at 480V. It features a non-interchangeable instantaneous trip, a 210–700A magnetic range, and a 16.1–59.1A motor FLA range. The breaker has a feed-thru configuration and includes non-aluminum line- and load-side lug terminals.

Specifications:

• Manufacturer: Eaton / Cutler-Hammer / Westinghouse
• Product Type: Molded Case Circuit Breaker
• Product Name: Motor Circuit Protector (MCP)
• Product Family: Series C
• Series: Series C
• Type: HMCP
• Frame: F-Frame
• Catalog No.: HMCP070M2C
• Current Rating: 70A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V
• Interrupting Rating: 65kA @ 480V
• Protection Type: Magnetic Only
• Trip Function: Instantaneous (I)
• Trip Type: Non-Interchangeable
• Mounting / Configuration: Feed-Thru
• Terminal Configuration: Non-Aluminum Line- and Load-Side Lug Terminals
• Magnetic Range: 210–700A
• Motor FLA Range: 16.1–59.1A
• Application: Motor Circuit Protection
• Brand: Eaton / Cutler-Hammer

Part Numbers & Identification:

• Manufacturer Part Number (MPN): HMCP070M2C
• Catalog Number: HMCP070M2C
• Product Family: Eaton Series C Molded Case Circuit Breakers
• Series: Series C
• Type: HMCP
• Frame: F-Frame
• Brand: Eaton / Cutler-Hammer
• Manufacturer: Eaton
• Product Type: Motor Circuit Protector / Molded Case Circuit Breaker
• Model: HMCP070M2C
• Breaker Configuration: 3-Pole, 70A
• upc:
  786679150849

Compatibility:

Designed for use with compatible Eaton / Cutler-Hammer Series C Type HMCP motor circuit protection applications. The HMCP070M2C is a 3-pole, 70A MCP with magnetic-only instantaneous protection, a 210–700A magnetic range, and a 16.1–59.1A motor FLA range.

The breaker uses a feed-thru configuration and includes non-aluminum line- and load-side lug terminals. Always verify the specific motor application, panelboard or electrical equipment model, approved MCP type, system voltage, available fault current, pole configuration, magnetic trip requirements, terminal arrangement, and installation requirements before installation.

Certifications:

• Series C HMCP
• F-Frame
• 70A Rated
• 3-Pole / 3-Phase
• 600V Rated
• 65kA @ 480V Interrupting Rating
• Magnetic-Only Protection
• Instantaneous (I) Protection
• Non-Interchangeable Trip
• Feed-Thru Configuration
• Non-Aluminum Line- and Load-Side Lug Terminals
• 210–700A Magnetic Range
• 16.1–59.1A Motor FLA Range
• Motor Circuit Protector (MCP)
