Eaton HMCP100R3C Molded Case Circuit Breaker – 100A – 3-Pole – 600V – 65kA – Feed-Thru – Series C HMCP

The Eaton Cutler-Hammer HMCP100R3C is a 100A, 3-pole, 3-phase motor circuit protector (MCP) from the Series C HMCP F-Frame family. It is rated for 600V with a 65kA interrupting capacity at 480V and features magnetic-only instantaneous protection.

The breaker has a non-interchangeable trip, with an adjustable magnetic range of 300–1000A, and is designed for motor circuit protection applications. It includes non-aluminum line- and load-side lug terminals and a feed-thru configuration.

Specifications:

• Brand: Eaton / Cutler-Hammer / Westinghouse
• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Series: Series C
• Type: HMCP
• Frame: F-Frame
• Catalog No.: HMCP100R3C
• Current Rating: 100A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V
• Interrupting Rating: 65kA at 480V
• Breaker Type: Motor Circuit Protector (MCP)
• Protection Type: Magnetic Only
• Trip Function: I – Instantaneous Protection Only
• Trip Type: Non-Interchangeable
• Magnetic Range: 300–1000A
• Motor FLA Range: 23.0–84.5A
• Connection Type: Feed-Thru
• Line-Side Terminals: Non-Aluminum Lug Terminals
• Load-Side Terminals: Non-Aluminum Lug Terminals
• Application: Motor Circuit Protection
• Product Family: HMCP F-Frame Molded Case Circuit Breakers

Part Numbers & Identification:

• Manufacturer Part Number (MPN): HMCP100R3C
• Catalog Number: HMCP100R3C
• Product Family: Series C HMCP
• Type: HMCP
• Frame: F-Frame
• Brand: Eaton / Cutler-Hammer / Westinghouse
• Manufacturer: Eaton
• Product Type: Motor Circuit Protector
• Model: HMCP100R3C
• Breaker Configuration: 3-Pole, 100A
• upc:   786679150856

Compatibility:

Designed for use with compatible Eaton / Cutler-Hammer / Westinghouse Series C HMCP F-Frame motor circuit protection applications. The HMCP100R3C is intended for motor circuits requiring magnetic-only instantaneous protection and is rated for 100A at 600V, with a 65kA interrupting capacity at 480V.

Always verify the motor full-load current, magnetic trip range, system voltage, interrupting rating, approved equipment, terminal requirements, and installation configuration before installation.

Certifications:

• Series C HMCP
• F-Frame
• 100A Rating
• 3-Pole / 3-Phase
• 600V Rated
• 65kA Interrupting Capacity at 480V
• Motor Circuit Protector (MCP)
• Magnetic-Only Protection
• Instantaneous Protection
• Feed-Thru Configuration
• Non-Interchangeable Trip
• Genuine Eaton / Cutler-Hammer Product
