Eaton HMCP150T4C Molded Case Circuit Breaker – 150A – 3-Pole – 600V – 65kA @ 480V – Feed-Thru – Series C HMCP

The Eaton HMCP150T4C is a 150A, 3-pole molded case circuit breaker from the Series C HMCP family. It is a motor circuit protector (MCP) designed for motor circuit applications and provides instantaneous magnetic protection only. The breaker has a 600V rating, a 65kA interrupting rating at 480V, feed-thru configuration, and a non-interchangeable trip.

It features non-aluminum line and load-side lug terminals and a magnetic adjustment range of 450–1500A. The breaker is suitable for compatible motor circuit protection applications with motor FLA requirements within the specified 34.6–126.7A range.

Specifications:

• Manufacturer: Eaton / Cutler-Hammer / Westinghouse
• Product Type: Molded Case Circuit Breaker
• Catalog No.: HMCP150T4C
• Product Family: Series C
• Series: HMCP
• Frame: F-Frame
• Current Rating: 150A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V
• Interrupting Rating: 65kA @ 480V
• Mounting/Connection: Feed-Thru
• Trip Type: Non-Interchangeable
• Protection Type: Instantaneous Magnetic Protection Only
• Breaker Type: Motor Circuit Protector (MCP)
• Magnetic Range: 450–1500A
• Motor FLA Range: 34.6–126.7A
• Terminal Type: Non-Aluminum Line & Load Side Lug Terminals
• Trip Function: Instantaneous (I)
• Protection: Magnetic Only
• Application: Motor Circuit Protection

Part Numbers & Identification:

• Manufacturer Part Number (MPN): HMCP150T4C
• Catalog Number: HMCP150T4C
• Product Family: Eaton Series C
• Series: HMCP
• Frame: F-Frame
• Brand: Eaton
• Manufacturer: Eaton / Cutler-Hammer / Westinghouse
• Product Type: Molded Case Circuit Breaker
• Model: HMCP150T4C
• Breaker Configuration: 3-Pole, 150A
• Breaker Type: Motor Circuit Protector (MCP)
• upc:786679150863

Compatibility:

Designed for use in compatible Eaton / Cutler-Hammer Series C HMCP motor circuit protection applications. The HMCP150T4C is a 3-pole, 150A motor circuit protector with instantaneous magnetic protection and a 450–1500A magnetic range.

The specified motor FLA range is 34.6–126.7A. Always verify the specific motor application, system voltage, available fault current, panelboard or equipment compatibility, terminal configuration, and applicable installation requirements before installation.

Certifications:

• Series C HMCP
• F-Frame
• 3-Pole / 3-Phase
• 150A Rated
• 600V Rated
• 65kA @ 480V
• Motor Circuit Protector (MCP)
• Instantaneous Magnetic Protection Only
• Non-Interchangeable Trip
• Feed-Thru Configuration
