Eaton HMCP150U4C Molded Case Circuit Breaker – 150A – 3-Pole – 600V – 65kA – Feed-Thru – Series C HMCP

The Eaton Cutler-Hammer HMCP150U4C is a 150A, 3-pole, 3-phase molded case motor circuit protector (MCP) from the Series C HMCP family. It is rated for 600V and provides a 65kA interrupting rating at 480V.

The HMCP150U4C features magnetic-only instantaneous protection, with a non-interchangeable trip and an adjustable magnetic range of 750–2500A. It uses a feed-thru configuration and includes non-aluminum line- and load-side lug terminals. The device is designed for motor circuit protection applications and has a motor FLA range of 57.0–130.7A.

Specifications:

• Manufacturer: Eaton / Cutler-Hammer / Westinghouse
• Brand: Eaton / Cutler-Hammer
• Product Type: Molded Case Circuit Breaker
• Series: Series C
• Type: HMCP
• Frame: F Frame
• Catalog No.: HMCP150U4C
• Current Rating: 150A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V
• Interrupting Rating: 65kA at 480V
• Connection: Feed-Thru
• Trip Type: Non-Interchangeable
• Protection: I – Instantaneous Protection Only
• Protection Type: Magnetic Only
• Device Type: MCP – Motor Circuit Protector
• Magnetic Range: 750–2500A
• Motor FLA Range: 57.0–130.7A
• Line-Side Terminals: Non-Aluminum Lugs
• Load-Side Terminals: Non-Aluminum Lugs

Part Numbers & Identification:

• Manufacturer Part Number (MPN): HMCP150U4C
• Catalog Number: HMCP150U4C
• Product Family: Eaton Series C HMCP
• Brand: Eaton / Cutler-Hammer
• Manufacturer: Eaton
• Product Type: Molded Case Motor Circuit Protector
• Model: HMCP150U4C
• Frame: F Frame
• Breaker Configuration: 3-Pole, 150A
• Device Classification: MCP – Motor Circuit Protector
• upc:786679150870

Compatibility:

Designed for use with compatible Eaton / Cutler-Hammer / Westinghouse Series C HMCP motor circuit protection applications. The HMCP150U4C is configured for 3-phase, 150A, 600V applications and provides magnetic-only instantaneous protection for motor circuits.

Always verify the specific motor application, controller or starter, panelboard or switchboard, system voltage, motor full-load amperage, magnetic trip range, interrupting rating, terminal configuration, and manufacturer-approved installation requirements before installation.

Certifications:

• Series C HMCP
• F Frame
• 150A Rating
• 3-Pole / 3-Phase
• 600V Rated
• 65kA Interrupting Rating at 480V
• Feed-Thru Configuration
• Magnetic-Only Protection
• Instantaneous Protection
• 750–2500A Magnetic Range
• 57.0–130.7A Motor FLA Range
• Non-Interchangeable Trip
• Non-Aluminum Line & Load Lugs
