Eaton Cutler-Hammer HMCPE030H1 30 Amp Motor Circuit Protector – 3 Pole – 480V / 600Y/347V – Series G

The Eaton Cutler-Hammer HMCPE030H1 is a Series G, Type HMCPE motor circuit protector featuring an EG frame and a 30 A rating. This three-pole, three-phase device provides magnetic-only instantaneous protection through a non-interchangeable trip mechanism. It has a magnetic trip range of 90–330 A, supports motor full-load currents of 3.9–26.1 A, and includes non-aluminum line- and load-side lug terminals.

Specifications

• Brand: Eaton / Cutler-Hammer
• Catalog Number: HMCPE030H1
• Product Type: Motor Circuit Protector (MCP)
• Series: Series G
• Type: HMCPE
• Frame: EG frame
• Rated Current: 30 A
• Poles: 3
• Phases: 3-phase
• Voltage Rating: 480 V; 600Y/347 V AC
• Reference Temperature: 40°C
• Trip Type: Magnetic-only
• Trip Configuration: Non-interchangeable
• Protection Function: Instantaneous protection only
• Magnetic Trip Range: 90–330 A
• Motor Full-Load Current Range: 3.9–26.1 A
• Connection Type: Feed-through
• Terminals: Non-aluminum line- and load-side lug terminals

Part Numbers & Identification

• Manufacturer: Eaton
• Brand Family: Cutler-Hammer
• Model / MPN: HMCPE030H1
• Series Identification: Series G, Type HMCPE
• Frame Identification: EG frame
• Device Classification: Motor Circuit Protector (MCP)
• UPC:786679150825

Compatibility

Suitable for Eaton Series G motor control applications requiring a 30 A motor circuit protector with magnetic-only instantaneous protection and a motor full-load current within the specified range.
