Eaton HMCPE050K2C Motor Circuit Protector – 50A – 3-Pole / 3-Phase – 600V AC / 250V DC – Adjustable Magnetic – Feed-Thru – Series C F-Frame

The Eaton HMCPE050K2C is a 50A, 3-pole, 3-phase Motor Circuit Protector (MCP) from the Eaton Series C F-Frame family. It is designed specifically for motor branch circuit protection and provides instantaneous-only magnetic protection rather than thermal-magnetic protection.

The MCP features an adjustable magnetic trip setting from 150A to 500A, allowing the protection level to be adjusted for the specific motor application. It is designed to operate with a motor starter and overload relay to provide coordinated motor branch circuit protection.

Specifications:

• Manufacturer: Eaton
• Product Type: Motor Circuit Protector (MCP)
• Product Family: Series C
• Frame: F-Frame
• Catalog No.: HMCPE050K2C
• Current Rating: 50A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• AC Voltage Rating: 600V AC
• DC Voltage Rating: 250V DC
• Frequency Rating: 50/60 Hz
• Protection Type: Magnetic-Only
• Trip Function: Instantaneous-Only Magnetic
• Trip Setting: Adjustable
• Magnetic Trip Range: 150–500A
• Connection / Configuration: Feed-Thru
• Terminals: Standard Line- and Load-Side Terminals
• Interrupting Capacity: Dependent on the Starter/Contactor Pairing
• Application: Motor Branch Circuit Protection, Motor Control Centers, Motor Starter Combinations, and Industrial Automation

Part Numbers & Identification:

• Manufacturer Part Number (MPN): HMCPE050K2C
• Catalog Number: HMCPE050K2C
• Model: HMCPE050K2C
• Product Family: Eaton Series C Motor Circuit Protectors
• Series: Series C
• Frame: F-Frame
• Brand: Eaton
• Manufacturer: Eaton
• Product Type: Motor Circuit Protector (MCP)
• Breaker Configuration: 3-Pole, 50A
• UPC:786679113677

Compatibility:

Designed for use with compatible Eaton Series C motor starter and motor-control applications. The HMCPE050K2C is intended to provide instantaneous magnetic protection for motor branch circuits and is used in conjunction with appropriate overload protection for complete motor protection.

Certifications:

• UL Listed
• CSA Certified
• IEC Rated
• Series C
• F-Frame
• 50A Rated
• 3-Pole / 3-Phase
• 600V AC Rated
• 250V DC Rated
• Instantaneous-Only Magnetic Protection
• Adjustable 150–500A Magnetic Trip
• Feed-Thru Configuration
