Eaton Cutler-Hammer HMCPE050K2Y 50 Amp Motor Circuit Protector – 3 Pole – 480 Vac – Series G

The Eaton Cutler-Hammer HMCPE050K2Y is a Series G, Type HMCPE motor circuit protector (MCP) with an EG frame and a 50 A rating. This three-pole device provides magnetic-only instantaneous protection through a non-interchangeable trip mechanism. It features a magnetic trip range of 150–550 A and non-aluminum line- and load-side lug terminals.

Specifications

• Brand: Eaton
• Manufacturer: Cutler-Hammer
• MPN: HMCPE050K2Y
• Product Type: Motor Circuit Protector (MCP)
• Series: Series G
• Breaker Type: HMCPE
• Frame Type: EG frame
• Current Rating: 50 A
• Number of Poles: 3
• Phase: 3-phase
• Voltage Rating: 480 Vac
• Additional Voltage Rating: 600Y/347 Vac
• Trip Type: Magnetic-only
• Trip Configuration: Non-interchangeable
• Protection Function: Instantaneous (I) protection only
• Magnetic Trip Range: 150–550 A
• Motor Full-Load Amperage Range: 11.5–43.5 A
• Ambient Temperature Rating: 40°C
• Connection Configuration: Feed-through
• Terminal Material: Non-aluminum line- and load-side lug terminals

Part Numbers & Identification

• Catalog Number: HMCPE050K2Y
• Manufacturer: Eaton Cutler-Hammer
• Product Family: Series G
• Frame Designation: EG
• Device Classification: Three-pole magnetic motor circuit protector
• UPC:786679113677

Compatibility

Suitable for compatible Eaton Series G motor control applications requiring a 50 A motor circuit protector with magnetic-only instantaneous protection and a motor full-load current within the specified range.
