Eaton HMCPE100R3Y 100 Amp Motor Circuit Protector – 3 Pole – 480 V / 600Y/347 V AC – Magnetic-Only – Series G

The Eaton HMCPE100R3Y is a 100 Amp, 3-pole, 3-phase motor circuit protector from the Eaton / Cutler-Hammer Series G, Type HMCPE, EG-Frame product range. It is rated for 480 V and 600Y/347 V AC and features a non-interchangeable trip unit with instantaneous protection. This magnetic-only protector is designed for motor circuit protection and includes non-aluminum line and load-side lug terminals. Its magnetic range is 330–1100 A, with a motor full-load amperage range of 23.0–87.0 A.

Specifications

• Manufacturer: Eaton
• Brand: Cutler-Hammer
• Product Type: Motor Circuit Protector (MCP)
• Series: Series G
• Type: HMCPE
• Frame: EG Frame
• Catalog Number / MPN: HMCPE100R3Y
• Primary Rating: 100 Amp
• Poles / Configuration: 3 Pole
• Phase: 3 Phase
• Voltage: 480 V / 600Y/347 V AC
• Trip Type: Magnetic Only
• Trip Unit: Non-Interchangeable
• Trip Functions: I – Instantaneous Protection Only
• Magnetic Range: 330–1100 A
• Motor FLA Range: 23.0–87.0 A
• Connection / Mounting: Feed-Thru
• Terminals: Non-Aluminum Line & Load-Side Lug Terminals
• Calibration Code: 40CB0C

Part Numbers & Identification

• Manufacturer: Eaton
• Brand: Cutler-Hammer
• Catalog Number: HMCPE100R3Y
• Series: Series G
• Type: HMCPE
• Frame: EG Frame
• Current Rating: 100 A
• Pole Count: 3 Pole
• Product Type: Magnetic-Only Motor Circuit Protector
• Trip Unit: Non-Interchangeable
• Trip Functions: I – Instantaneous Protection Only
• Connection: Feed-Thru
• Terminals: Non-Aluminum Line & Load-Side Lug Terminals


Compatibility

The Eaton HMCPE100R3Y is intended for compatible Eaton / Cutler-Hammer Series G motor circuit protection applications.
