Eaton HMCPS015E0C Motor Circuit Protector – 15A – 3-Pole / 3-Phase – 600V – 65kA @ 480V – Feed-Thru – Series C HMCPS

The Eaton HMCPS015E0C is a 15A, 3-pole, 3-phase molded case motor circuit protector (MCP) from the Eaton Series C Type HMCPS F-Frame. It provides magnetic-only, instantaneous protection for motor circuits rather than thermal-magnetic protection.

The HMCPS015E0C is rated for 600V and provides a 65kA interrupting rating at 480V. It features a non-interchangeable instantaneous trip, a 45–150A magnetic range, and a 3.4–12.6A motor FLA range. The breaker has a feed-thru configuration and includes non-aluminum line-side and load-side lug terminals.

It is designed for motor starter applications equipped with electronic overload relays, where the overload protection is provided separately.

Specifications:

• Manufacturer: Eaton / Cutler-Hammer / Westinghouse
• Product Type: Molded Case Motor Circuit Protector
• Product Name: Motor Circuit Protector (MCP)
• Product Family: Series C
• Series: HMCPS
• Type: HMCPS
• Frame: F-Frame
• Catalog No.: HMCPS015E0C
• Current Rating: 15A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V
• Interrupting Rating: 65kA @ 480V
• Protection Type: Magnetic Only
• Trip Function: Instantaneous (I) Protection Only
• Trip Type: Non-Interchangeable
• Mounting / Configuration: Feed-Thru
• Terminal Type: Non-Aluminum Line-Side and Load-Side Lug Terminals
• Magnetic Range: 45–150A
• Motor FLA Range: 3.4–12.6A
• Application: Motor Circuit Protection
• Motor Starter Application: Motor Starters with Electronic Overload Relays

Part Numbers & Identification:

• Manufacturer Part Number (MPN): HMCPS015E0C
• Catalog Number: HMCPS015E0C
• Model: HMCPS015E0C
• Product Family: Eaton Series C Molded Case Motor Circuit Protectors
• Series: HMCPS
• Type: HMCPS
• Frame: F-Frame
• Brand: Eaton / Cutler-Hammer
• Manufacturer: Eaton
• Product Type: Motor Circuit Protector (MCP)
• Breaker Configuration: 3-Pole, 15A

Compatibility:

Designed for compatible Eaton / Cutler-Hammer Series C Type HMCPS motor starter applications equipped with electronic overload relays. The HMCPS015E0C provides magnetic-only instantaneous protection and is intended to be used with separate electronic overload protection.

The MCP features a 45–150A magnetic range, 3.4–12.6A motor FLA range, feed-thru configuration, and non-aluminum line- and load-side lug terminals.

Always verify the specific motor starter, panelboard or electrical equipment model, approved MCP type, system voltage, available fault current, motor FLA, magnetic trip requirements, terminal arrangement, and installation requirements before installation.

Certifications:

• Series C HMCPS
• F-Frame
• 15A Rated
• 3-Pole / 3-Phase
• 600V Rated
• 65kA @ 480V Interrupting Rating
• Magnetic-Only Protection
• Instantaneous (I) Protection Only
• Non-Interchangeable Trip
• Feed-Thru Configuration
• Non-Aluminum Line-Side and Load-Side Lug Terminals
• 45–150A Magnetic Range
• 3.4–12.6A Motor FLA Range
• Motor Circuit Protector (MCP)
