Eaton HMCPS015E0W Molded Case Circuit Breaker – 15A – 3-Pole / 3-Phase – 600V – 65kA @ 480V – Feed-Thru – Series C HMCPS

The Eaton HMCPS015E0W is a 15A, 3-pole, 3-phase magnetic-only molded case motor circuit protector (MCP) from the Eaton / Cutler-Hammer / Westinghouse Series C Type HMCPS F-Frame. It is designed for motor starter applications equipped with electronic overload relays.

The HMCPS015E0W is rated for 600V and provides a 65kA interrupting rating at 480V. It features instantaneous protection only, a non-interchangeable trip, a 45–150A magnetic range, and a 3.4–12.6A motor FLA range. The breaker uses a feed-thru configuration with non-aluminum line- and load-side lug terminals.

Specifications:

• Manufacturer: Eaton / Cutler-Hammer / Westinghouse
• Product Type: Molded Case Circuit Breaker
• Product Name: Motor Circuit Protector (MCP)
• Product Family: Series C
• Series: Series C
• Type: HMCPS
• Frame: F-Frame
• Catalog No.: HMCPS015E0W
• Current Rating: 15A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V
• Interrupting Rating: 65kA @ 480V
• Protection Type: Magnetic Only
• Trip Type: Non-Interchangeable
• Trip Function: Instantaneous (I) Protection Only
• Mounting / Configuration: Feed-Thru
• Terminal Type: Non-Aluminum Line- and Load-Side Lug Terminals
• Magnetic Range: 45–150A
• Motor FLA Range: 3.4–12.6A
• Application: Motor Circuit Protection with Motor Starters Equipped with Electronic Overload Relays
• Breaker Configuration: Complete Breaker
• Brand: Eaton / Cutler-Hammer

Part Numbers & Identification:

• Manufacturer Part Number (MPN): HMCPS015E0W
• Catalog Number: HMCPS015E0W
• Model: HMCPS015E0W
• Product Family: Eaton Series C Molded Case Circuit Breakers
• Series: Series C
• Type: HMCPS
• Frame: F-Frame
• Brand: Eaton / Cutler-Hammer
• Manufacturer: Eaton
• Product Type: Motor Circuit Protector / Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 15A
• Trip Configuration: Non-Interchangeable, Instantaneous Only

Compatibility:

Designed for compatible Eaton / Cutler-Hammer / Westinghouse Series C Type HMCPS motor circuit protection applications, particularly motor starters equipped with electronic overload relays.

The HMCPS015E0W provides magnetic-only instantaneous protection with a 45–150A magnetic range and 3.4–12.6A motor FLA range. It uses a feed-thru configuration with non-aluminum line- and load-side lug terminals. Always verify the specific motor starter, electrical equipment model, system voltage, available fault current, motor FLA, magnetic trip requirements, terminal arrangement, and installation requirements before installation.

Certifications:

• Series C HMCPS
• F-Frame
• 15A Rated
• 3-Pole / 3-Phase
• 600V Rated
• 65kA @ 480V Interrupting Rating
• Magnetic-Only Protection
• Instantaneous (I) Protection Only
• Non-Interchangeable Trip
• Feed-Thru Configuration
• Non-Aluminum Line- and Load-Side Lug Terminals
• 45–150A Magnetic Range
• 3.4–12.6A Motor FLA Range
• Motor Circuit Protector (MCP)
