Eaton HMCPS050K2C Molded Case Circuit Breaker – 50A – 3-Pole / 3-Phase – 600V – 65kA @ 480V – Feed-Thru – Series C HMCPS

The Eaton HMCPS050K2C is a 50A, 3-pole, 3-phase molded case motor circuit protector (MCP) from the Eaton / Cutler-Hammer / Westinghouse Series C Type HMCPS F-Frame. It provides magnetic-only, instantaneous protection for motor branch circuits rather than thermal-magnetic protection.

The HMCPS050K2C is rated for 600V and provides a 65kA interrupting rating at 480V. It features a feed-thru configuration, a non-interchangeable instantaneous trip, and non-aluminum line- and load-side lug terminals. It is designed for applications with motor starters equipped with electronic overload relays.

Specifications:

• Manufacturer: Eaton / Cutler-Hammer / Westinghouse
• Product Type: Molded Case Circuit Breaker
• Product Name: Motor Circuit Protector (MCP)
• Product Family: Series C
• Series: Series C
• Type: HMCPS
• Frame: F-Frame
• Catalog No.: HMCPS050K2C
• Current Rating: 50A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V
• Interrupting Rating: 65kA @ 480V
• Temperature Rating: 40°C
• Protection Type: Magnetic Only
• Trip Function: Instantaneous (I) Protection Only
• Trip Type: Non-Interchangeable
• Mounting / Configuration: Feed-Thru
• Terminal Configuration: Non-Aluminum Line- and Load-Side Lug Terminals
• Magnetic Range: 150–500A
• Motor FLA Range: 11.5–42.1A
• Product Type/Application: Motor Circuit Protector for Motor Starters with Electronic Overload Relays
• Application: Motor Circuit Protection

Part Numbers & Identification:

• Manufacturer Part Number (MPN): HMCPS050K2C
• Catalog Number: HMCPS050K2C
• Model: HMCPS050K2C
• Product Family: Eaton Series C Molded Case Circuit Breakers
• Series: Series C
• Type: HMCPS
• Frame: F-Frame
• Brand: Eaton / Cutler-Hammer
• Manufacturer: Eaton
• Product Type: Motor Circuit Protector / Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 50A
• Trip Function: Instantaneous (I)
• Protection: Magnetic Only
• UPC:786679232644

Compatibility:

Designed for compatible Eaton / Cutler-Hammer Series C Type HMCPS motor circuit protection applications used with motor starters equipped with electronic overload relays. The HMCPS050K2C provides 50A magnetic-only protection with an adjustable 150–500A magnetic range and a 11.5–42.1A motor FLA range.

The breaker uses a feed-thru configuration with non-aluminum line- and load-side lug terminals. ns:

• Series C HMCPS
• F-Frame
• 50A Rated
• 3-Pole / 3-Phase
• 600V Rated
• 65kA @ 480V Interrupting Rating
• 40°C Rated
• Magnetic-Only Protection
• Instantaneous (I) Protection Only
• Non-Interchangeable Trip
• Feed-Thru Configuration
• Non-Aluminum Line- and Load-Side Lug Terminals
• 150–500A Magnetic Range
• 11.5–42.1A Motor FLA Range
• Motor Circuit Protector (MCP)
