Eaton HMCPS100R3C 100 Amp Molded Case Circuit Breaker – 3 Pole – 600 V – 65 kA@480 V – Feed-Thru – Series C

The Eaton HMCPS100R3C is a 100 Amp, 3-pole motor circuit protector from the Eaton / Cutler-Hammer / Westinghouse Series C, Type HMCPS, F-Frame product range. It is rated for 600 V with a 65 kA interrupting rating at 480 V and is designed for feed-thru mounting. This magnetic-only molded case circuit breaker provides instantaneous protection and is intended for use with motor starters equipped with electronic overload relays.

Specifications

• Manufacturer: Eaton
• Brand: Cutler-Hammer
• Product Type: Motor Circuit Protector (MCP)
• Series: Series C
• Type: HMCPS
• Frame: F Frame
• Catalog Number / MPN: HMCPS100R3C
• Primary Rating: 100 Amp
• Poles / Configuration: 3 Pole
• Phase: 3 Phase
• Voltage: 600 V
• Interrupting Rating: 65 kA @ 480 V
• Connection / Mounting: Feed-Thru
• Trip Type: Magnetic Only
• Trip Functions: I – Instantaneous Protection Only
• Trip Unit: Non-Interchangeable
• Magnetic Range: 300–1000 A
• Motor FLA Range: 23.0–84.5 A
• Terminals: Non-Aluminum Line & Load-Side Lug Terminals
• Application: Motor Starters with Electronic Overload Relays
• UPC:786679150856

Compatibility

The Eaton HMCPS100R3C is designed for compatible Eaton / Cutler-Hammer Series C motor starter applications equipped with electronic overload relays.
