Eaton HMCPS150U4C 150 Amp Molded Case Circuit Breaker – 3 Pole – 600 V – 65 kA@480 V – Feed-Thru – Series C

The Eaton HMCPS150U4C is a 150 Amp, 3-pole molded case circuit breaker from the Eaton / Cutler-Hammer / Westinghouse Series C, Type HMCPS. It is a motor circuit protector (MCP) with magnetic-only protection and instantaneous trip functionality. The breaker is designed for use with motor starters equipped with electronic overload relays and features a non-interchangeable trip unit, feed-thru mounting, and non-aluminum line & load-side lug terminals.

Specifications

• Manufacturer: Eaton
• Brand: Cutler-Hammer
• Product Type: Molded Case Circuit Breaker
• Series: Series C
• Type: HMCPS
• Frame: F Frame
• Catalog Number / MPN: HMCPS150U4C
• Primary Rating: 150 Amp
• Poles / Configuration: 3 Pole
• Phase: 3 Phase
• Voltage: 600 V
• Interrupting Rating: 65 kA@480 V
• Interrupting Capacity: Standard
• Ambient Temperature Rating: 40°C
• Trip Type: Magnetic Only
• Trip Unit: Non-Interchangeable
• Trip Function: I – Instantaneous Protection Only
• Connection / Mounting: Feed-Thru
• Terminals: Non-Aluminum Line & Load-Side Lug Terminals
• Application: Motor Circuit Protector (MCP)
• Magnetic Range: 750–2500 A
• Motor FLA Range: 57.0–130.7 A
• Application: Motor Starters with Electronic Overload Relays
• UPC:786679232705

Compatibility

The Eaton HMCPS150U4C is designed for compatible Eaton / Cutler-Hammer / Westinghouse Series C motor circuit protector applications with motor starters equipped with electronic overload relays.
