HNF363 – Siemens 100A 600V 3-Pole Non-Fusible Safety Switch NEMA 1

Key Specifications

• Amperage: 100 A

• Voltage Rating: 600 V AC

• Poles: 3

• Wires: 3

• Fusible: No (Non-fusible)

• Enclosure: Painted steel, NEMA 1

• Interrupt Rating: 200 kA @ 600 V

• Mounting Type: Surface mount

• Series/Frame: VBII Series

• Certifications: UL Listed, UL 98

• Application: Heavy commercial, industrial, service entrance

Specifications

• Part Number: HNF363

• Manufacturer: Siemens

• Category: Switch

• Item Subcategory: Disconnect

• Family: VBII Series

• Type: HNF

• Voltage: 600 AC

• Amperage: 100

• Phase: 3

• Poles: 3

• AIC Rating: 200 kA @ 600 V

• Fuse Class: Non-fusible

• Configuration: Single

• Switch Style: Non-fusible

• NEMA Rating: NEMA 1

• Compatible Frames: PGP

Product Data

• UPC: 783643151185

• GTIN: 00783643151185

• Country of Origin: Mexico

• Dimensions: 12.0 in x 23.1 in (W x H)

• Weight: ~33 lbs

• Certifications: UL Listed, UL 98
