Square D HRA36060U31X 60 Amp Molded Case Circuit Breaker – 3 Pole – 600 V – 200 kA@480 V – I-Line Plug-In – PowerPact Series

The Square D HRA36060U31X is a 60 Amp, 3-pole, 3-phase molded case circuit breaker from Schneider Electric / Square D PowerPact, Type HRA. It is rated for 600 V with an interrupting capacity of 200 kA at 480 V and 100 kA at 600 V. The breaker features I-Line style plug-in mounting, Phase ABC configuration, and an 80% rating. It is UL Listed.

Specifications

• Manufacturer: Schneider Electric
• Brand: Square D
• Product Type: Molded Case Circuit Breaker
• Series: PowerPact
• Type: HRA
• Catalog Number / MPN: HRA36060U31X
• Primary Rating: 60 Amp
• Poles / Configuration: 3 Pole
• Phase: 3 Phase
• Voltage: 600 V
• Interrupting Rating: 200 kA @ 480 V; 100 kA @ 600 V
• Connection / Mounting: I-Line Style Plug-In
• Phase Sequence: ABC
• Rating: 80% Rated

Part Numbers & Identification

• Manufacturer: Schneider Electric
• Brand: Square D
• Catalog Number: HRA36060U31X
• Series: PowerPact
• Type: HRA
• Current Rating: 60 A
• Pole Count: 3 Pole
• Product Type: Molded Case Circuit Breaker
• Mounting: I-Line Style Plug-In
• Phase Sequence: ABC
• UPC: 785901943778

Compatibility

The Square D HRA36060U31X is designed for compatible Square D PowerPact HRA molded case circuit breaker applications using I-Line style plug-in mounting. Verify the specific I-Line panelboard, system voltage, phase configuration, and breaker compatibility before installation.

Certifications

• UL Listed
