Intermatic WH2725AT 30A DPST – 7-Day Pre-Programmed – Water Heater Timer – 240V

The Intermatic WH2725AT 30A DPST – 7-Day Pre-Programmed – Water Heater Timer – 240V provides dependable 7-day scheduling for 240V, 30 Amp water heater circuits. Designed for residential, agricultural, and specialty applications, this timer features DPST (Double-Pole Single-Throw) contacts, automatic Daylight Saving Time adjustment, and a 100-hour battery-free supercapacitor backup. Housed in a NEMA 3R outdoor-rated metal enclosure, it ensures durable performance and precise energy control while meeting code requirements.

Voltage and Rating

• Voltage Rating: 240 Volts AC, 60 Hz
• Amperage Rating: 30 Amps
• Contact Form: DPST (Double-Pole Single-Throw)
• Power Consumption: 5 Watts

Key Specifications

• Timer Type: Pre-Programmed 7-Day Water Heater Timer
• Operation Mode: 7-Day Programming
• Max Events: 16 fixed OFF events
• Enclosure Type: NEMA 3R (outdoor-rated metal)
• Operating Temperature Range: -40°F to 122°F
• Backup Power: 100-hour supercapacitor (battery-free)
• Features: Automatic DST adjustment, lockout feature for city code compliance, zero-crossing relay technology, 1-hour temporary override
• Applications: Water heater control, agriculture feeders, greenhouse misting control
• Certifications: UL Listed, CSA

Technical Specifications

• Operating Mechanism: Electric programmable timer
• Mounting Mode: Surface or wall mount

Product Data

• Manufacturer: Intermatic
• Brand: Intermatic
• Model Number: WH2725AT
• UPC: 078275149991

Dimensions

• • Width: 6.5 in
  • Depth: 3.625 in
  • Height: 10.125 in
