Eaton JD3125 125 Amp Molded Case Circuit Breaker – 3 Pole – 600 V AC / 250 V DC – 35 kAIC@480 V AC – Fixed Thermal-Magnetic – Series C

The Eaton JD3125 is a 125 Amp, 3-pole molded case circuit breaker from the Eaton / Cutler-Hammer Series C, J-frame product range. It is rated for 600 V AC and 250 V DC and features fixed thermal and fixed magnetic trip protection. The breaker provides interrupting ratings of 65 kAIC at 240 V AC and 35 kAIC at 480 V AC. It uses aluminum line and load-side connections and operates at 50/60 Hz.

Specifications

• Manufacturer: Eaton
• Brand: Cutler-Hammer
• Product Type: Molded Case Circuit Breaker
• Series: Series C
• Type: JD
• Frame: J-Frame
• Catalog Number / MPN: JD3125
• Primary Rating: 125 Amp
• Poles / Configuration: 3 Pole
• Voltage: 600 V AC
• DC Voltage: 250 V DC
• Interrupting Rating: 65 kAIC @ 240 V AC; 35 kAIC @ 480 V AC
• Trip Type: Fixed Thermal / Fixed Magnetic
• Terminals: Aluminum Line & Load-Side Connections
• Frequency: 50/60 Hz
• Assembly: Complete Circuit Breaker

Part Numbers & Identification

• Manufacturer: Eaton
• Brand: Cutler-Hammer
• Catalog Number: JD3125
• Series: Series C
• Type: JD
• Frame: J-Frame
• Current Rating: 125 A
• Pole Count: 3 Pole
• Product Type: Molded Case Circuit Breaker
• Trip Configuration: Fixed Thermal / Fixed Magnetic
• Connection: Line and Load
• Terminals: Aluminum
• UPC:786679013540

Compatibility

The Eaton JD3125 is intended for compatible Eaton / Cutler-Hammer Series C J-frame electrical distribution and circuit protection applications.
