Eaton Cutler-Hammer JD3150W 150 Amp Molded Case Circuit Breaker – 3 Pole – 600V – 35 kA @ 480V – Series C

The Eaton Cutler-Hammer JD3150W is a Series C Type JD, three-pole, 150A molded case circuit breaker designed for electrical circuit protection. It features a thermal-magnetic trip mechanism with interchangeable Long-Time and Instantaneous (LI) trip functions. The breaker has a 600V rating, 35 kA interrupting capacity at 480V, and bolt-on mounting.

Specifications

• Brand: Eaton / Cutler-Hammer
• Series: Series C
• Type: JD
• Frame: JD
• Amperage Rating: 150A
• Number of Poles: 3
• Phase: 3-Phase
• Voltage Rating: 600V
• Interrupting Capacity: 35 kA @ 480V
• Interrupting Rating: Standard
• Trip Unit: Interchangeable LI (Long-Time and Instantaneous)
• Trip Mechanism: Thermal-Magnetic
• Mounting: Bolt-on
• Terminals: Load-side lug terminals
• Temperature Rating: 40°C

Part Numbers & Identification

• MPN: JD3150W
• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Frame Type: JD
• Series: C
• UPC:786679031377

Compatibility

Suitable for Eaton Series C Type JD applications requiring a 150A, three-pole molded case circuit breaker with interchangeable LI trip functions and bolt-on mounting.
