Eaton JD3250K Molded Case Circuit Breaker – 250A – 3-Pole / 3-Phase – 600V – 35kA @ 480V – Bolt-On – Series C JD

The Eaton JD3250K is a 250A, 3-pole, 3-phase molded case circuit breaker from the Eaton / Cutler-Hammer / Westinghouse Series C Type JD. It is configured as a non-automatic switch with no overcurrent protection and includes a non-interchangeable trip unit.

The JD3250K is rated for 600V and provides a 35kA interrupting rating at 480V with standard interrupting capacity. It features a bolt-on mounting configuration and includes load-side lug terminals.

Specifications:

• Manufacturer: Eaton / Cutler-Hammer / Westinghouse
• Product Type: Molded Case Circuit Breaker
• Product Family: Series C
• Series: Series C
• Type: JD
• Catalog No.: JD3250K
• Current Rating: 250A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V
• Interrupting Rating: 35kA @ 480V
• Interrupting Capacity: Standard
• Overcurrent Protection: None (NA)
• Trip Unit: Non-Interchangeable
• Switch Type: Non-Automatic
• Mounting Type: Bolt-On
• Terminal Type: Load-Side Lug Terminals
• Application: Electrical Switching / Distribution Equipment

Part Numbers & Identification:

• Manufacturer Part Number (MPN): JD3250K
• Catalog Number: JD3250K
• Model: JD3250K
• Product Family: Eaton Series C Molded Case Circuit Breakers
• Series: Series C
• Type: JD
• Brand: Eaton / Cutler-Hammer
• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 250A
• Trip Configuration: Non-Interchangeable Trip Unit
• Switch Configuration: Non-Automatic, No Overcurrent Protection
• UPC:786679516423

Compatibility:

Designed for use with compatible Eaton / Cutler-Hammer Series C Type JD electrical distribution equipment that accepts JD Series molded case circuit breakers or switches.

The JD3250K is a 250A, 3-pole, 600V bolt-on device with a non-interchangeable trip unit, load-side lug terminals, and no overcurrent protection. Always verify the specific panelboard or electrical equipment model, approved device type, system voltage, available fault current, pole configuration, terminal arrangement, and installation requirements before installation.
