Square D JGA36250 Molded Case Circuit Breaker – 250A – 3-Pole – 600V – 35kA @ 480V – I-Line Plug-In – PowerPact JGA Series

The Square D JGA36250 is a 250A, 3-pole, 3-phase molded case circuit breaker from the PowerPact JGA Series. It is rated for 600V and provides a 35kA interrupting rating at 480V. The breaker features thermal-magnetic protection, a non-interchangeable trip, and Long-Time and Instantaneous (LI) trip functions.

The JGA36250 uses an I-Line style plug-in connection with ABC phase connection. It is UL Listed and suitable for reverse-fed applications.

Specifications:

• Manufacturer: Square D / Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Series: PowerPact JGA
• Type: JGA
• Catalog No.: JGA36250
• Current Rating: 250A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Phase Connection: ABC
• Voltage Rating: 600V
• Interrupting Rating: 35kA @ 480V
• Interrupting Capacity: High
• Protection Type: Thermal-Magnetic
• Trip Unit: Non-Interchangeable
• Trip Functions: Long-Time and Instantaneous (LI)
• Mounting / Connection: I-Line Style Plug-In
• Application: Electrical Distribution and Overcurrent Protection
• Reverse Feed: Suitable for Reverse-Fed Applications

Part Numbers & Identification:

• Manufacturer Part Number (MPN): JGA36250
• Catalog Number: JGA36250
• Product Family: PowerPact Molded Case Circuit Breakers
• Series: JGA
• Type: JGA
• Brand: Square D
• Manufacturer: Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Model: JGA36250
• Breaker Configuration: 3-Pole, 250A
• upc:785901939139

Compatibility:

Designed for use with compatible Square D / Schneider Electric PowerPact JGA Series electrical distribution equipment supporting I-Line style plug-in circuit breakers. The JGA36250 is a 3-pole, 250A, 600V thermal-magnetic MCCB with a 35kA interrupting rating at 480V, LI trip functions, and an ABC phase connection.

The breaker is suitable for reverse-fed applications as specified. Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, I-Line connection, and installation requirements before installation.

Certifications:

• UL Listed
• 35kA Interrupting Rating @ 480V
• High Interrupting Capacity
• Thermal-Magnetic Protection
• Long-Time and Instantaneous (LI) Trip
• Non-Interchangeable Trip
• I-Line Style Plug-In
• Suitable for Reverse-Fed Applications
• Genuine Square D / Schneider Electric Product
