Eaton Cutler-Hammer JGE305033G 50 Amp Molded Case Circuit Breaker – 3 Pole – 600 Vac – 65 kAIC – Series G

The Eaton Cutler-Hammer JGE305033G is a Series G electronic molded case circuit breaker featuring a JG frame, a 50-ampere current rating, and a Digitrip 310 RMS electronic LS trip unit. Its protection functions include long-time and short-time protection, as provided by the LS trip configuration. Rated for 600 Vac and 250 Vdc, it offers interrupting capacities of 65 kAIC at 240 Vac, 25 kAIC at 480 Vac, and 18 kAIC at 600 Vac. Line and load connections support installation in compatible electrical distribution systems operating at 50/60 Hz.

Specifications

• Brand: Eaton
• Manufacturer: Cutler-Hammer
• MPN: JGE305033G
• Product Type: Electronic Molded Case Circuit Breaker (MCCB)
• Series: Series G
• Frame Type: JG frame
• Current Rating: 50 A
• Number of Poles: 3
• Trip Unit: Digitrip 310 RMS
• Trip Type: Electronic LS
• Protection Functions: Long-time and short-time protection
• AC Voltage Rating: 600 Vac
• DC Voltage Rating: 250 Vdc
• Interrupting Capacity at 240 Vac: 65 kAIC
• Interrupting Capacity at 480 Vac: 25 kAIC
• Interrupting Capacity at 600 Vac: 18 kAIC
• Connection Configuration: Line and load
• Frequency: 50/60 Hz

Part Numbers & Identification

• Catalog Number: JGE305033G
• Model Number: JGE305033G
• Product Family: Eaton Cutler-Hammer Series G
• Frame Designation: JG
• Trip Unit Identification: Digitrip 310 RMS
• Configuration: 3-pole, 50 A electronic MCCB with LS protection
• UPC:782116017874

Compatibility

Designed for compatible Eaton Cutler-Hammer Series G JG-frame applications requiring a 50 A, three-pole electronic breaker with a Digitrip 310 RMS LS trip unit.
