JGE310036G - Eaton - Molded Case CiEaton Cutler-Hammer JGE310036G 100 Amp Molded Case Circuit Breaker – 3 Pole – 600 Vac – 65 kAIC – Series Grcuit Breaker

The Eaton Cutler-Hammer JGE310036G is a Series G electronic molded case circuit breaker featuring a JG frame and a 100-ampere current rating. It is equipped with a Digitrip 310 RMS electronic LSIG trip unit, providing long-time, short-time, instantaneous, and ground-fault protection. Rated for applications up to 600 Vac and 250 Vdc, it offers interrupting capacities of 65 kAIC at 240 Vac, 25 kAIC at 480 Vac, and 18 kAIC at 600 Vac. Line and load connections support integration into compatible electrical distribution systems operating at 50/60 Hz.

Specifications

• Brand: Eaton
• Manufacturer: Cutler-Hammer
• MPN: JGE310036G
• Product Type: Electronic Molded Case Circuit Breaker (MCCB)
• Series: Series G
• Frame Type: JG frame
• Current Rating: 100 A
• Number of Poles: 3
• Trip Unit: Digitrip 310 RMS
• Trip Type: Electronic LSIG
• Protection Functions: Long-time, short-time, instantaneous, and ground-fault protection
• AC Voltage Rating: 600 Vac
• DC Voltage Rating: 250 Vdc
• Interrupting Capacity at 240 Vac: 65 kAIC
• Interrupting Capacity at 480 Vac: 25 kAIC
• Interrupting Capacity at 600 Vac: 18 kAIC
• Connection Configuration: Line and load
• Frequency: 50/60 Hz

Part Numbers & Identification

• Catalog Number: JGE310036G
• Model Number: JGE310036G
• Product Family: Eaton Cutler-Hammer Series G
• Frame Designation: JG
• Trip Unit Identification: Digitrip 310 RMS
• Configuration: 3-pole, 100 A electronic MCCB with LSIG protection
• UPC:782116999392

Compatibility

Suitable for compatible Eaton Cutler-Hammer Series G JG-frame applications requiring a 100 A, three-pole electronic breaker with a Digitrip 310 RMS LSIG trip unit. Confirm voltage, interrupting capacity, mounting, and terminal compatibility before installation or replacement.
