Eaton Cutler-Hammer JGE3100AAG 100 Amp Molded Case Circuit Breaker – 3 Pole – 600 Vac – 65 kAIC – Series G

The Eaton Cutler-Hammer JGE3100AAG is a Series G molded case circuit breaker featuring a JG frame, a 100-ampere current rating, and adjustable thermal and magnetic trip protection. Rated for applications up to 600 Vac and 250 Vdc, it provides short-circuit interrupting capacities of 65 kAIC at 240 Vac, 25 kAIC at 480 Vac, and 18 kAIC at 600 Vac. Line and load connections support integration into compatible electrical distribution systems operating at 50/60 Hz.

Specifications

• Brand: Eaton
• Manufacturer: Cutler-Hammer
• MPN: JGE3100AAG
• Product Type: Molded Case Circuit Breaker (MCCB)
• Series: Series G
• Frame Type: JG frame
• Current Rating: 100 A
• Number of Poles: 3
• Trip Type: Adjustable thermal and adjustable magnetic
• AC Voltage Rating: 600 Vac
• DC Voltage Rating: 250 Vdc
• Interrupting Capacity at 240 Vac: 65 kAIC
• Interrupting Capacity at 480 Vac: 25 kAIC
• Interrupting Capacity at 600 Vac: 18 kAIC
• Connection Configuration: Line and load
• Frequency: 50/60 Hz

Part Numbers & Identification

• Catalog Number: JGE3100AAG
• Model Number: JGE3100AAG
• Product Family: Eaton Cutler-Hammer Series G
• Frame Designation: JG
• Configuration: 3-pole, 100 A, adjustable thermal-magnetic MCCB
• UPC:782114886199

Compatibility

Suitable for electrical distribution applications requiring a compatible Eaton Cutler-Hammer Series G JG-frame, 100 A, three-pole breaker. Confirm voltage, interrupting capacity, mounting arrangement, and terminal compatibility before installation or replacement.
