Eaton Cutler-Hammer JGE3125AAG 125 Amp Molded Case Circuit Breaker – 3 Pole – 600 Vac – 65 kAIC at 240 Vac – Series G

The Eaton Cutler-Hammer JGE3125AAG is a Series G complete molded case circuit breaker featuring a JG frame and a 125 A current rating. It uses an adjustable thermal and adjustable magnetic trip mechanism to provide circuit protection. This three-pole breaker is rated for 600 Vac, with interrupting capacities of 65 kAIC at 240 Vac, 25 kAIC at 480 Vac, and 18 kAIC at 600 Vac. It supports line and load connections, operates at 50/60 Hz, and uses metric specifications.

Specifications

• Brand: Eaton
• Manufacturer: Cutler-Hammer
• Product Type: Molded Case Circuit Breaker (MCCB)
• Series: Series G
• Frame Type: JG frame
• Catalog Number: JGE3125AAG
• Current Rating: 125 A
• Number of Poles: 3
• Breaker Assembly: Complete breaker
• Trip Type: Adjustable thermal, adjustable magnetic
• Voltage Rating: 600 Vac
• Interrupting Capacity at 240 Vac: 65 kAIC
• Interrupting Capacity at 480 Vac: 25 kAIC
• Interrupting Capacity at 600 Vac: 18 kAIC
• Connection Type: Line and load
• Measurement System: Metric
• Frequency: 50/60 Hz

Part Numbers & Identification

• MPN: JGE3125AAG
• Model: JGE3125AAG
• Product Family: Eaton Cutler-Hammer Series G
• Frame Designation: JG
• Breaker Configuration: Three-pole, 125 A MCCB
• Assembly Type: Complete breaker
• Trip Configuration: Adjustable thermal, adjustable magnetic
• UPC:782114886205

Compatibility

Designed for electrical distribution systems requiring an Eaton Cutler-Hammer Series G JG-frame, three-pole, 125 A circuit breaker with matching voltage and interrupting-capacity requirements. Confirm panel compatibility, mounting arrangement, and terminal configuration before installation or replacement.
