Eaton JGE3150FAGC 150 Amp Molded Case Circuit Breaker – 3 Pole – 600 V AC – 65 kA@240 V – 25 kA@480 V – 18 kA@600 V – JG Frame – Series G – 100% Rated

The Eaton JGE3150FAGC is a 150 Amp, 3-pole molded case circuit breaker from the Eaton Series G JG-frame product family. It features fixed thermal protection and adjustable magnetic trip protection. Rated for 600 V AC, the breaker provides interrupting ratings of 65 kAIC at 240 V, 25 kAIC at 480 V, and 18 kAIC at 600 V. It includes line- and load-side connections and is designed for 100% rated applications.

Specifications

• Manufacturer: Eaton
• Brand: Eaton
• Product Type: Molded Case Circuit Breaker
• Series: Series G
• Type: JG
• Frame: JG Frame
• Catalog Number / MPN: JGE3150FAGC
• Primary Rating: 150 Amp
• Poles / Configuration: 3 Pole
• Voltage: 600 V AC
• Frequency: 50/60 Hz
• Interrupting Rating: 65 kAIC @ 240 V AC; 25 kAIC @ 480 V AC; 18 kAIC @ 600 V AC
• Thermal Protection: Fixed Thermal
• Magnetic Protection: Adjustable Magnetic
• Connection: Line and Load
• Measurement System: Metric
• Rated Capacity: 100% Rated

Part Numbers & Identification

• Manufacturer: Eaton
• Brand: Eaton
• Catalog Number: JGE3150FAGC
• Series: Series G
• Type: JG
• Frame: JG Frame
• Current Rating: 150 A
• Pole Count: 3 Pole
• Product Type: Thermal-Magnetic Molded Case Circuit Breaker
• Trip Configuration: Fixed Thermal, Adjustable Magnetic
• Rated Capacity: 100% Rated
• UPC:786685290836

Compatibility

The Eaton JGE3150FAGC is intended for compatible Eaton Series G JG-frame electrical distribution applications.
