Eaton JGE316036G 160 Amp Molded Case Circuit Breaker – 3 Pole – 600 V AC – 25 kAIC@480 V AC – Electronic LSIG Trip – Series G

The Eaton JGE316036G is a 160 Amp, 3-pole molded case circuit breaker from the Eaton / Cutler-Hammer Series G, JG-frame product range. It features a Digitrip 310 RMS electronic trip unit with LSIG (Long-Time, Short-Time, Instantaneous, and Ground-Fault) protection functions. The breaker provides multiple interrupting ratings depending on system voltage and is rated at 80% of its specified continuous current rating. This model is specified as not UL rated and includes line and load-side connections.

Specifications

• Manufacturer: Eaton
• Brand: Cutler-Hammer
• Product Type: Electronic Molded Case Circuit Breaker
• Series: Series G
• Frame: JG Frame
• Catalog Number / MPN: JGE316036G
• Primary Rating: 160 Amp
• Poles / Configuration: 3 Pole
• Interrupting Rating: 65 kAIC @ 240 V AC; 25 kAIC @ 415/480 V AC; 18 kAIC @ 600 V AC
• Trip Type: Electronic
• Trip Unit: Digitrip 310 RMS
• Trip Functions: LSIG – Long-Time, Short-Time, Instantaneous, and Ground-Fault
• Terminals: Line & Load-Side Connections
• Continuous Rating: 80% Rated
• UL Rating: Not UL Rated
• Assembly: Complete Circuit Breaker

Part Numbers & Identification

• Manufacturer: Eaton
• Brand: Cutler-Hammer
• Catalog Number: JGE316036G
• Series: Series G
• Frame: JG Frame
• Current Rating: 160 A
• Pole Count: 3 Pole
• Product Type: Electronic Molded Case Circuit Breaker
• Trip Unit: Digitrip 310 RMS
• Trip Functions: LSIG – Long-Time, Short-Time, Instantaneous, and Ground-Fault
• Connection: Line / Load
• Continuous Rating: 80% Rated
• UPC:782116999408

Compatibility

The Eaton JGE316036G is intended for compatible Eaton Series G JG-frame electrical distribution and circuit protection applications.
