Eaton Cutler-Hammer JGH305036G 50 Amp Molded Case Circuit Breaker – 3 Pole – 600 Vac / 250 Vdc – 100 kAIC at 240 Vac – Series G

The Eaton Cutler-Hammer JGH305036G is a Series G electronic molded case circuit breaker featuring a JG frame and a 50 A current rating. It is equipped with a Digitrip 310 RMS electronic LSIG trip unit, providing long-time, short-time, instantaneous, and ground-fault protection. This three-pole breaker supports ratings of 600 Vac and 250 Vdc, with AC interrupting capacities of 100 kAIC at 240 Vac, 65 kAIC at 480 Vac, and 25 kAIC at 600 Vac. It supports line and load connections and operates at 50/60 Hz.

Specifications

• Brand: Eaton
• Manufacturer: Cutler-Hammer
• Product Type: Electronic Molded Case Circuit Breaker (MCCB)
• Series: Series G
• Frame Type: JG frame
• Catalog Number: JGH305036G
• Current Rating: 50 A
• Number of Poles: 3
• Trip Unit: Digitrip 310 RMS
• Trip Type: Electronic LSIG
• Protection Functions: Long-time, short-time, instantaneous, and ground-fault protection
• AC Voltage Rating: 600 Vac
• DC Voltage Rating: 250 Vdc
• Interrupting Capacity at 240 Vac: 100 kAIC
• Interrupting Capacity at 480 Vac: 65 kAIC
• Interrupting Capacity at 600 Vac: 25 kAIC
• Connection Type: Line and load
• Frequency: 50/60 Hz

Part Numbers & Identification

• MPN: JGH305036G
• Model: JGH305036G
• Product Family: Eaton Cutler-Hammer Series G
• Frame Designation: JG
• Trip Unit Identification: Digitrip 310 RMS
• Breaker Configuration: Three-pole, 50 A electronic MCCB
• Trip Configuration: Electronic LSIG

Compatibility

Designed for electrical distribution systems requiring an Eaton Cutler-Hammer Series G JG-frame, three-pole, 50 A electronic circuit breaker with a Digitrip 310 RMS LSIG trip unit. Confirm applicable AC or DC system requirements, interrupting capacity, mounting arrangement, and terminal compatibility before installation.
