Eaton Cutler-Hammer JGH3100AAG 100 Amp Molded Case Circuit Breaker – 3 Pole – 600 Vac – 100 kAIC – Series G

The Eaton Cutler-Hammer JGH3100AAG is a Series G molded case circuit breaker featuring a JG frame, a 100-ampere current rating, and adjustable thermal and magnetic trip protection. Designed to protect compatible electrical distribution systems against overloads and short circuits, it is rated for 600 Vac and 250 Vdc. The breaker provides interrupting capacities of 100 kAIC at 240 Vac, 65 kAIC at 480 Vac, and 25 kAIC at 600 Vac. It supports line and load connections and operates at 50/60 Hz.

Specifications

• Brand: Eaton
• Manufacturer: Cutler-Hammer
• MPN: JGH3100AAG
• Product Type: Molded Case Circuit Breaker (MCCB)
• Series: Series G
• Frame Type: JG frame
• Current Rating: 100 A
• Number of Poles: 3
• Trip Type: Adjustable thermal and adjustable magnetic
• AC Voltage Rating: 600 Vac
• DC Voltage Rating: 250 Vdc
• Interrupting Capacity at 240 Vac: 100 kAIC
• Interrupting Capacity at 480 Vac: 65 kAIC
• Interrupting Capacity at 600 Vac: 25 kAIC
• Connection Configuration: Line and load
• Frequency: 50/60 Hz

Part Numbers & Identification

• Catalog Number: JGH3100AAG
• Model Number: JGH3100AAG
• Product Family: Eaton Cutler-Hammer Series G
• Frame Designation: JG
• Configuration: 3-pole, 100 A adjustable thermal-magnetic MCCB
• UPC:782114886311

Compatibility

Designed for compatible Eaton Cutler-Hammer Series G JG-frame applications requiring a 100 A, three-pole breaker.
