Eaton Cutler-Hammer JGH316033G 160 Amp Molded Case Circuit Breaker – 3 Pole – 600 Vac – 100 kAIC – Series G

The Eaton Cutler-Hammer JGH316033G is a Series G electronic molded case circuit breaker featuring a JG frame, a 160-ampere current rating, and a Digitrip 310 RMS electronic LS trip unit. Its LS protection provides long-time and short-time protection against overloads and short-circuit conditions. Rated for 600 Vac, it offers interrupting capacities of 100 kAIC at 240 Vac, 65 kAIC at 480 Vac, and 25 kAIC at 600 Vac. The breaker supports line/load connections, follows metric specifications, and operates at 50/60 Hz.

Specifications

• Brand: Eaton
• Manufacturer: Cutler-Hammer
• MPN: JGH316033G
• Product Type: Electronic Molded Case Circuit Breaker (MCCB)
• Series: Series G
• Frame Type: JG frame
• Current Rating: 160 A
• Number of Poles: 3
• Trip Unit: Digitrip 310 RMS
• Trip Type: Electronic LS
• Protection Functions: Long-time and short-time protection
• AC Voltage Rating: 600 Vac
• Interrupting Capacity at 240 Vac: 100 kAIC
• Interrupting Capacity at 480 Vac: 65 kAIC
• Interrupting Capacity at 600 Vac: 25 kAIC
• Connection Configuration: Line/load
• Measurement System: Metric
• Frequency: 50/60 Hz

Part Numbers & Identification

• Catalog Number: JGH316033G
• Model Number: JGH316033G
• Product Family: Eaton Cutler-Hammer Series G
• Frame Designation: JG
• Trip Unit Identification: Digitrip 310 RMS
• Configuration: 3-pole, 160 A electronic MCCB with LS protection
• UPC:782116018055

Compatibility

Designed for compatible Eaton Cutler-Hammer Series G JG-frame applications requiring a 160 A, three-pole electronic breaker with Digitrip 310 RMS LS protection.
