Eaton Cutler-Hammer JGH316036G 160 Amp Molded Case Circuit Breaker – 3 Pole – 600 Vac – 100 kAIC – Series G

The Eaton Cutler-Hammer JGH316036G is a Series G electronic molded case circuit breaker featuring a JG frame, a 160-ampere current rating, and a Digitrip 310 RMS electronic trip unit with LSIG protection. Its protection functions include long-time, short-time, instantaneous, and ground-fault protection. The breaker provides interrupting capacities of 100 kAIC at 240 Vac, 70 kAIC at 415 Vac, 65 kAIC at 480 Vac, and 25 kAIC at 600 Vac. It is supplied as a complete breaker with line/load connections, is 80% rated.

Specifications

• Brand: Eaton
• Manufacturer: Cutler-Hammer
• MPN: JGH316036G
• Product Type: Electronic Molded Case Circuit Breaker (MCCB)
• Series: Series G
• Frame Type: JG frame
• Current Rating: 160 A
• Number of Poles: 3
• Breaker Configuration: Complete breaker
• Trip Unit: Digitrip 310 RMS
• Trip Type: Electronic LSIG
• Protection Functions: Long-time, short-time, instantaneous, and ground-fault protection
• Interrupting Capacity at 240 Vac: 100 kAIC
• Interrupting Capacity at 415 Vac: 70 kAIC
• Interrupting Capacity at 480 Vac: 65 kAIC
• Interrupting Capacity at 600 Vac: 25 kAIC
• Connection Configuration: Line/load
• Continuous Rating: 80% rated
• UL Rating: Not UL rated

Part Numbers & Identification

• Catalog Number: JGH316036G
• Model Number: JGH316036G
• Product Family: Eaton Cutler-Hammer Series G
• Frame Designation: JG
• Trip Unit Identification: Digitrip 310 RMS
• Configuration: 3-pole, 160 A electronic MCCB with LSIG protection


Compatibility

Designed for compatible Eaton Cutler-Hammer Series G JG-frame applications requiring a 160 A, three-pole electronic breaker with Digitrip 310 RMS LSIG protection.
