Eaton Cutler-Hammer JGH3160AAG 160 Amp Molded Case Circuit Breaker – 3 Pole – 600 Vac – 100 kAIC – Series G

The Eaton Cutler-Hammer JGH3160AAG is a Series G molded case circuit breaker featuring a JG frame and a 160-ampere current rating. It uses adjustable thermal and adjustable magnetic trip protection to protect compatible electrical distribution systems against overloads and short circuits. Rated for 600 Vac, it provides interrupting capacities of 100 kAIC at 240 Vac, 65 kAIC at 480 Vac, and 25 kAIC at 600 Vac. The breaker supports line and load connections, uses metric specifications, and operates at 50/60 Hz.

Specifications

• Brand: Eaton
• Manufacturer: Cutler-Hammer
• MPN: JGH3160AAG
• Product Type: Molded Case Circuit Breaker (MCCB)
• Series: Series G
• Frame Type: JG frame
• Current Rating: 160 A
• Number of Poles: 3
• Trip Type: Adjustable thermal and adjustable magnetic
• AC Voltage Rating: 600 Vac
• Interrupting Capacity at 240 Vac: 100 kAIC
• Interrupting Capacity at 480 Vac: 65 kAIC
• Interrupting Capacity at 600 Vac: 25 kAIC
• Connection Configuration: Line and load
• Measurement System: Metric
• Frequency: 50/60 Hz

Part Numbers & Identification

• Catalog Number: JGH3160AAG
• Model Number: JGH3160AAG
• Product Family: Eaton Cutler-Hammer Series G
• Frame Designation: JG
• Configuration: 3-pole, 160 A, adjustable thermal-magnetic MCCB
• UPC:782114886335

Compatibility

Designed for compatible Eaton Cutler-Hammer Series G JG-frame applications requiring a 160 A, three-pole breaker.
