Eaton JGS305033G 50 Amp Molded Case Circuit Breaker – 3 Pole – 600 V AC / 250 V DC – 35 kAIC@480 V AC – Electronic LS Trip – Series G

The Eaton JGS305033G is a 50 Amp, 3-pole electronic molded case circuit breaker from the Eaton / Cutler-Hammer Series G, JG-frame product range. It is rated for 600 V AC and 250 V DC and features a Digitrip 310 RMS electronic trip unit with LS (Long-Time and Short-Time) protection functions. The breaker provides multiple interrupting ratings depending on system voltage and includes line and load-side connections.

Specifications

• Manufacturer: Eaton
• Brand: Cutler-Hammer
• Product Type: Electronic Molded Case Circuit Breaker
• Series: Series G
• Frame: JG Frame
• Catalog Number / MPN: JGS305033G
• Primary Rating: 50 Amp
• Poles / Configuration: 3 Pole
• Voltage: 600 V AC
• DC Voltage: 250 V DC
• Interrupting Rating: 85 kAIC @ 240 V AC; 35 kAIC @ 480 V AC; 18 kAIC @ 600 V AC
• Trip Type: Electronic
• Trip Unit: Digitrip 310 RMS
• Trip Functions: LS – Long-Time and Short-Time
• Terminals: Line & Load-Side Connections
• Frequency: 50/60 Hz

Part Numbers & Identification

• Manufacturer: Eaton
• Brand: Cutler-Hammer
• Catalog Number: JGS305033G
• Series: Series G
• Frame: JG Frame
• Current Rating: 50 A
• Pole Count: 3 Pole
• Product Type: Electronic Molded Case Circuit Breaker
• Trip Unit: Digitrip 310 RMS
• Trip Functions: LS – Long-Time and Short-Time
• Connection: Line and Load
• UPC:782116017959

Compatibility

The Eaton JGS305033G is intended for compatible Eaton Series G JG-frame electrical distribution and circuit protection applications.
