Eaton Cutler-Hammer JGS3100AAG 100 Amp Molded Case Circuit Breaker – 3 Pole – 600 Vac / 250 Vdc – 85 kAIC at 240 Vac – Series G

The Eaton Cutler-Hammer JGS3100AAG is a Series G molded case circuit breaker featuring a JG frame and a 100 A current rating. It uses an adjustable thermal and adjustable magnetic trip mechanism for circuit protection. This three-pole breaker is rated for 600 Vac and 250 Vdc, with AC interrupting capacities of 85 kAIC at 240 Vac, 35 kAIC at 480 Vac, and 18 kAIC at 600 Vac. It supports line and load connections and operates at 50/60 Hz.

Specifications

• Brand: Eaton
• Manufacturer: Cutler-Hammer
• Product Type: Molded Case Circuit Breaker (MCCB)
• Series: Series G
• Frame Type: JG frame
• Catalog Number: JGS3100AAG
• Current Rating: 100 A
• Number of Poles: 3
• Trip Type: Adjustable thermal, adjustable magnetic
• AC Voltage Rating: 600 Vac
• DC Voltage Rating: 250 Vdc
• Interrupting Capacity at 240 Vac: 85 kAIC
• Interrupting Capacity at 480 Vac: 35 kAIC
• Interrupting Capacity at 600 Vac: 18 kAIC
• Connection Type: Line and load
• Frequency: 50/60 Hz
• Continuous Rating: Not specified
• Mounting Type: Not specified

Part Numbers & Identification

• MPN: JGS3100AAG
• Model: JGS3100AAG
• Product Family: Eaton Cutler-Hammer Series G
• Frame Designation: JG
• Breaker Configuration: Three-pole, 100 A MCCB
• Trip Configuration: Adjustable thermal, adjustable magnetic
• UPC:782114886250

Compatibility

Designed for electrical distribution systems requiring an Eaton Cutler-Hammer Series G JG-frame, three-pole, 100 A circuit breaker with matching AC or DC system requirements and interrupting capacity. Confirm panel compatibility, mounting arrangement, and terminal configuration before installation or replacement.
