Eaton Cutler-Hammer JGS3160AAG 160 Amp Molded Case Circuit Breaker – 3 Pole – 600 Vac – 85 kAIC at 240 Vac – Series G

The Eaton Cutler-Hammer JGS3160AAG is a Series G molded case circuit breaker featuring a JG frame and a 160 A current rating. It uses an adjustable thermal and adjustable magnetic trip mechanism for circuit protection. This three-pole breaker is rated for 600 Vac, with interrupting capacities of 85 kAIC at 240 Vac, 35 kAIC at 480 Vac, and 18 kAIC at 600 Vac. It supports line and load connections, operates at 50/60 Hz, and uses metric specifications. This model is identified as not UL rated.

Specifications

• Brand: Eaton
• Manufacturer: Cutler-Hammer
• Product Type: Molded Case Circuit Breaker (MCCB)
• Series: Series G
• Frame Type: JG frame
• Catalog Number: JGS3160AAG
• Current Rating: 160 A
• Number of Poles: 3
• Trip Type: Adjustable thermal, adjustable magnetic
• Voltage Rating: 600 Vac
• Interrupting Capacity at 240 Vac: 85 kAIC
• Interrupting Capacity at 480 Vac: 35 kAIC
• Interrupting Capacity at 600 Vac: 18 kAIC
• Connection Type: Line and load
• Measurement System: Metric
• Frequency: 50/60 Hz
• UL Rating: Not UL rated
• Continuous Rating: Not specified

Part Numbers & Identification

• MPN: JGS3160AAG
• Model: JGS3160AAG
• Product Family: Eaton Cutler-Hammer Series G
• Frame Designation: JG
• Breaker Configuration: Three-pole, 160 A MCCB
• Trip Configuration: Adjustable thermal, adjustable magnetic
• UPC:782114886274

Compatibility

Designed for electrical distribution systems requiring an Eaton Cutler-Hammer Series G JG-frame, three-pole, 160 A circuit breaker with matching voltage and interrupting-capacity requirements. Confirm panel compatibility, mounting arrangement, and terminal configuration before installation or replacement.
